STR-DA5400ES
17
two screws
(BVTP3 × 8)
two screws
(BVTP3 × 8)
eight screws
(B3 × 6)
four connectors
(CN3509, CN3607,
CN3609, CN3610)
connector
(CN3523)
RG two screws
(BVTP3 × 8)
RI two screws
(BVTP3 × 8)
RL two screws
(BVTP3 × 8)
RT two screws
(BVTP3 × 8)
two HS holders
two HS holders
bracket (HDMI-A64)
RK bracket (DMPORT-A64)
RM bracket (DM-HD)
heatsink (S58F)
heatsink (S58F)
R radiation sheet (F)
R radiation
sheet (F)
RB D VIDEO board
X DMPORT
board
RE 03P insulating bushing
five screws
(BVTP3 × 8)
RH
3-5. D VIDEO/DMPORT BOARDS
3-4. DSP/DIGITAL/CIS/CONTROL BOARDS
RB three screws
(BVTP3 × 8)
"
#
"
#
$
$
RE DIGITAL board
RT bracket (digital)
two screws
(BVTP3 × 8)
XG CONTROL
board
RH two screws
(BVTP3 × 8)
RL two screws
(BVTP3 × 8)
RK screws
(BVTP3 × 8)
XT two screws
(BVTP3 × 8)
XE two brackets
(control)
XB three connectors
(CN2516, CN2519,
CN2520)
D CONNECT board
RI CIS board
four connectors
(CN2403, CN2404,
CN2405, CN2406)
RM nine connectors
(CN2503, CN2504, CN2505,
CN2507, CN2508, CN2509,
CN2512, CN2513, CN2515)
eight screws
(BVTP3 × 8)
connector
(CN3571)
two connectors
(CN2204, CN2207)
connector
(CN2206)
R DSP board
four screws
(BVTP3 × 8)
RG wire (flat type) (13 core)
(CIS board (CN807),
D VIDEO board (CN2510))
