170
STR-DA5400ES
SECTION 8
ELECTRICAL PARTS LIST
A CLASS AMP BOARD
*****************
< CAPACITOR >
C1501 1-112-099-11 ELECT 4.7uF 20% 50V
C1502 1-101-810-00 CERAMIC 100PF 5% 500V
C1503 1-137-503-11 FILM 100PF 5% 100V
C1504 1-136-357-11 FILM 680PF 5% 100V
C1505 1-112-090-11 ELECT 100uF 20% 25V
C1507 1-107-587-11 CERAMIC 7PF 0.5PF 500V
C1508 1-112-421-11 ELECT 330uF 20% 25V
C1510 1-112-416-11 ELECT 220uF 20% 16V
C1511 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1515 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1551 1-112-099-11 ELECT 4.7uF 20% 50V
C1552 1-101-810-00 CERAMIC 100PF 5% 500V
C1553 1-137-503-11 FILM 100PF 5% 100V
C1554 1-136-357-11 FILM 680PF 5% 100V
C1555 1-112-090-11 ELECT 100uF 20% 25V
C1557 1-107-587-11 CERAMIC 7PF 0.5PF 500V
C1558 1-112-421-11 ELECT 330uF 20% 25V
C1560 1-112-416-11 ELECT 220uF 20% 16V
C1561 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1565 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1601 1-112-099-11 ELECT 4.7uF 20% 50V
C1602 1-101-810-00 CERAMIC 100PF 5% 500V
C1603 1-137-503-11 FILM 100PF 5% 100V
C1604 1-136-357-11 FILM 680PF 5% 100V
C1605 1-112-090-11 ELECT 100uF 20% 25V
C1607 1-107-587-11 CERAMIC 7PF 0.5PF 500V
C1608 1-112-421-11 ELECT 330uF 20% 25V
C1610 1-112-416-11 ELECT 220uF 20% 16V
C1611 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1615 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1701 1-112-099-11 ELECT 4.7uF 20% 50V
C1702 1-101-810-00 CERAMIC 100PF 5% 500V
C1703 1-137-503-11 FILM 100PF 5% 100V
C1704 1-136-357-11 FILM 680PF 5% 100V
C1705 1-112-090-11 ELECT 100uF 20% 25V
C1707 1-107-587-11 CERAMIC 7PF 0.5PF 500V
C1708 1-112-421-11 ELECT 330uF 20% 25V
C1710 1-112-416-11 ELECT 220uF 20% 16V
C1711 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1715 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1751 1-112-099-11 ELECT 4.7uF 20% 50V
C1752 1-101-810-00 CERAMIC 100PF 5% 500V
C1753 1-137-503-11 FILM 100PF 5% 100V
C1754 1-136-357-11 FILM 680PF 5% 100V
C1755 1-112-090-11 ELECT 100uF 20% 25V
C1757 1-107-587-11 CERAMIC 7PF 0.5PF 500V
C1758 1-112-421-11 ELECT 330uF 20% 25V
C1760 1-112-416-11 ELECT 220uF 20% 16V
C1761 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1765 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1801 1-112-099-11 ELECT 4.7uF 20% 50V
C1802 1-101-810-00 CERAMIC 100PF 5% 500V
C1803 1-137-503-11 FILM 100PF 5% 100V
C1804 1-136-357-11 FILM 680PF 5% 100V
C1805 1-112-090-11 ELECT 100uF 20% 25V
C1807 1-107-587-11 CERAMIC 7PF 0.5PF 500V
C1808 1-112-421-11 ELECT 330uF 20% 25V
C1810 1-112-416-11 ELECT 220uF 20% 16V
C1811 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1815 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1851 1-112-099-11 ELECT 4.7uF 20% 50V
C1852 1-101-810-00 CERAMIC 100PF 5% 500V
C1853 1-137-503-11 FILM 100PF 5% 100V
C1854 1-136-357-11 FILM 680PF 5% 100V
C1855 1-112-090-11 ELECT 100uF 20% 25V
C1857 1-107-587-11 CERAMIC 7PF 0.5PF 500V
C1858 1-112-421-11 ELECT 330uF 20% 25V
C1860 1-112-416-11 ELECT 220uF 20% 16V
C1861 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1865 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1901 1-112-109-11 ELECT 22uF 20% 100V
C1902 1-112-109-11 ELECT 22uF 20% 100V
C1911 1-126-791-11 ELECT 10uF 20% 35V
C1912 1-127-888-11 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
CN1504 1-764-864-41 CONNECTOR, BOARD TO BOARD 12P
CN1505 1-573-829-11 CONNECTOR, BOARD TO BOARD 15P
CN1905 1-764-864-41 CONNECTOR, BOARD TO BOARD 12P
CN1906 1-764-864-41 CONNECTOR, BOARD TO BOARD 12P
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A CLASS AMP
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• CAPACITORS
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
CND : Canadian model
ECE : Continental European, East Euro-
pean and Russian models
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifi é.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifi és par la marque
9 contiennent des informations confi den-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
