STR-DA5400ES
16
3-3. TUNER (FM/AM), SPTM BOARD
Note: Follow the disassembly procedure in the numerical order given.
3-2. CASE
flat head screw
(TP)
case
two flat head screws
(TP)
two spacers (case)
two screws
(
BVST4
×
8
)
two screws
(
BVST4
×
8
)
tuner (FM/AM)
wire (flat type) (9 core)
(US, Canadian models)
wire (flat type) (11 core)
(except US, Canadian models)
(tuner (FM/AM))
SPTM board
two screws (BV/ring)
four connectors
(CX4101, CX4102
CX4103, CX4104)
Cut the binding band (taiton).
two screws
(
BVTT2.6
×
6
)
w
w
w
.
x
i
a
o
y
u
