STR-DA5400ES
146
Pin No. Pin Name I/O Description
AD15 to
AD20
OCMADDR19,
OCMADDR15,
OCMADDR12,
OCMADDR8,
OCMADDR5,
OCMADDR1
O Address signal output to the fl ash memory
AD21 to
AD23
OCMDATA14,
OCMDATA10,
OCMDATA7
I/O Two-way data bus with the fl ash memory
AD24 ROM_CS_N O Chip enable signal output to the fl ash memory
AD25,
AD26
OCM_CS0N,
OCM_CS1N
O Chip select signal output terminal Not used
AE1 SV2P I Analog video signal (G) input from the OSD controller
AE2 B2P - Not used
AE3 AGND_ADC - Ground terminal
AE4 SV3P I Analog video signal (B) input from the OSD controller
AE5 B3P I Composite video signal input from the EXT VIDEO IN jack
AE6 AGND_ADC - Ground terminal
AE7 SV4P - Not used
AE8 BN2 - Not used
AE9 AGND_ADC - Ground terminal
AE10,
AE11
LBADC_IN2,
LBADC_IN6
- Not used
AE12 AIP_RAW_VS I Vertical sync signal input from the OSD controller
AE13 AVSOUT_SCL - Not used
AE14 AVSOUT_WORDSEL - Not used
AE15 to
AE20
OCMADDR20,
OCMADDR16,
OCMADDR13,
OCMADDR9,
OCMADDR6,
OCMADDR2
O Address signal output to the fl ash memory
AE21 to
AE26
OCMDATA15,
OCMDATA11,
OCMDATA8,
OCMDATA2 to
OCMDATA0
I/O Two-way data bus with the fl ash memory
AF1 A2P - Not used
AF2 C2P - Not used
AF3 BN - Not used
AF4 A3P I Composite video signal input from VIDEO IN 1 jack
AF5 C3P I Composite video signal input from VIDEO IN 2 jack
AF6 CN - Not used
AF7 AN2 - Not used
AF8 CN2 - Not used
AF9 SVN - Not used
AF10 LBADC_IN1 I Wake-up signal input from the video system controller
AF11 LBADC_IN5 - Not used
AF12 AIP_RAW_HS_CS I Horizontal sync signal input from the OSD controller
AF13 EXTOSD_CLK - Not used
AF14 AVSIN_SCL - Not used
AF15 to
AF20
OCMADDR21,
OCMADDR17,
OCMADDR14,
OCMADDR10,
OCMADDR7,
OCMADDR3
O Address signal output to the fl ash memory
AF21 OCMADDR0 O Address signal output terminal Not used
AF22 to
AF26
OCMDATA12,
OCMDATA9,
OCMDATA5 to
OCMDATA3
I/O Two-way data bus with the fl ash
