STR-DA5400ES
156
Pin No. Pin Name I/O Description
142
Faroudjia UCOM
BUSY
I Busy signal input from the video processor1
143
2nd Faro UCOM
UART Rx
I Serial data input from the video processor2
144
2nd Faro UCOM
UART Tx
O Serial data output to the video processor2
145
2nd Faro UCOM
BUSY
I Busy signal input from the video processor2
146 GND - Ground terminal
147 +5V - Power supply terminal (+3.3V)
148 to 160 NO USE -
Not used
161 GND - Ground terminal
162 +5V - Power supply terminal (+3.3V)
163
2nd Faro Power
DETECT
I Power detection signal input from the video processor2
164
2nd Faro UCOM
RESET
O Reset signal output to the video processor2 and fl ash memory "L": reset
165 2nd DAC CLOCK SEL O Clock control signal output to the frequency multiplier for D/A converter (for video section)
166 2nd VDAC_RESET O Reset signal output to the D/A converter (for video section) "L": reset
167 NO USE -
Not used
168 V.SYNC_DET I
Vertical sync signal input terminal Not used
169 TX_INT2 I Interrupt signal input from the HDMI transmitter
170 TX_RST2 O Reset signal output to the HDMI transmitter "L": reset
171 TX_5VPWR2 O Power supply on/off control signal output terminal for HDMI OUT connector "H": power on
172 CEC_SEL O
CEC line selection signal output terminal
173 REPEAT_PATH_SEL O
Signal path selection signal output terminal at repeater
174, 175 DAC_SW0, DAC_SW1 O
Not used
176 +5V -
Power supply terminal (+3.3V)
