Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA5400ES
179179
< IC >
IC802 6-700-587-01 IC TC7W53F (TE12R)
IC806 6-600-349-21 IC NJL23H400A
< JACK >
J801 1-563-330-31 JACK (IR REMOTE IN)
J802 1-563-330-31 JACK (IR REMOTE OUT 1)
J803 1-563-330-31 JACK (IR REMOTE OUT 2)
J821 1-563-330-31 JACK (TRIGGER OUT MAIN)
J831 1-563-330-31 JACK (TRIGGER OUT ZONE 2)
J841 1-563-330-31 JACK (TRIGGER OUT ZONE 3)
< TRANSISTOR >
Q821 8-729-037-13 TRANSISTOR KTA1271Y
Q822 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q831 8-729-037-13 TRANSISTOR KTA1271Y
Q832 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q841 8-729-037-13 TRANSISTOR KTA1271Y
Q842 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R801 1-216-833-11 METAL CHIP 10K 5% 1/10W
R802 1-216-797-11 METAL CHIP 10 5% 1/10W
R803 1-216-845-11 METAL CHIP 100K 5% 1/10W
R804 1-216-833-11 METAL CHIP 10K 5% 1/10W
R805 1-216-845-11 METAL CHIP 100K 5% 1/10W
R806 1-216-809-11 METAL CHIP 100 5% 1/10W
R807 1-216-809-11 METAL CHIP 100 5% 1/10W
R808 1-216-809-11 METAL CHIP 100 5% 1/10W
R809 1-216-295-91 SHORT CHIP 0
R811 1-216-150-91 METAL CHIP 10 5% 1/8W
R812 1-216-150-91 METAL CHIP 10 5% 1/8W
R822 1-216-833-11 METAL CHIP 10K 5% 1/10W
R823 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R824 1-216-833-11 METAL CHIP 10K 5% 1/10W
R825 1-216-809-11 METAL CHIP 100 5% 1/10W
R832 1-216-833-11 METAL CHIP 10K 5% 1/10W
R833 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R834 1-216-833-11 METAL CHIP 10K 5% 1/10W
R835 1-216-809-11 METAL CHIP 100 5% 1/10W
R842 1-216-833-11 METAL CHIP 10K 5% 1/10W
R843 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R844 1-216-833-11 METAL CHIP 10K 5% 1/10W
R845 1-216-809-11 METAL CHIP 100 5% 1/10W
< THERMISTOR >
TH821 1-801-726-11 THERMISTOR, POSITIVE
TH831 1-801-726-11 THERMISTOR, POSITIVE
TH841 1-801-726-11 THERMISTOR, POSITIVE
************************************************************
CONNECTOR1 BOARD
******************
< CONNECTOR >
CN1207 1-573-844-11 CONNECTOR, BOARD TO BOARD 12P
CN1209 1-573-844-11 CONNECTOR, BOARD TO BOARD 12P
************************************************************
CONNECTOR2 BOARD
******************
< CONNECTOR >
CN1205 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P
CN1206 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P
************************************************************
A-1538-081-A CONTROL BOARD, COMPLETE (US, CND)
A-1538-140-A CONTROL BOARD, COMPLETE (AEP, ECE, UK)
*************************
< CAPACITOR >
C2501 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2502 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2503 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2504 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2505 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2506 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2507 1-104-658-91 ELECT 100uF 20% 10V
C2508 1-126-947-11 ELECT 47uF 20% 35V
C2509 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2510 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2511 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2512 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2513 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2514 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2516 1-100-717-91 CERAMIC CHIP 1uF 16V
C2517 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2518 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2519 1-126-960-11 ELECT 1uF 20% 50V
C2520 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2521 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2522 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2523 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2524 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2525 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2526 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2527 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2528 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2530 1-104-662-91 ELECT 22uF 20% 25V
C2531 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2532 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2533 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2534 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2535 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2536 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2537 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2538 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2539 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2540 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2541 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2542 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2543 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2544 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2545 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2546 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2547 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2548 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2549 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2550 1-162-974-11 CERAMIC CHIP 0.01uF 50V
CIS CONNECTOR1 CONNECTOR2 CONTROL
