Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA5400ES
188
* FL3513 1-813-880-11 COMMON MODE CHOKE COIL
* FL3514 1-813-880-11 COMMON MODE CHOKE COIL
FL3601 1-400-874-11 FILTER, EMI REMOVAL (SMD)
FL3602 1-400-874-11 FILTER, EMI REMOVAL (SMD)
FL3603 1-400-874-11 FILTER, EMI REMOVAL (SMD)
FL3604 1-400-874-11 FILTER, EMI REMOVAL (SMD)
FL3605 1-400-874-11 FILTER, EMI REMOVAL (SMD)
FL3606 1-400-874-11 FILTER, EMI REMOVAL (SMD)
FL3607 1-400-874-11 FILTER, EMI REMOVAL (SMD)
FL3608 1-400-874-11 FILTER, EMI REMOVAL (SMD)
< IC >
IC3503 8-753-282-08 IC CXB1444R-T6
IC3504 8-753-282-08
IC CXB1444R-T6
IC3508 8-759-596-39 IC SN74LV4052APWR
IC3509 6-704-001-01 IC BR24L02F-WSE2
IC3511 (Not supplied) IC SII9135CTU
IC3513 (Not supplied) IC SII9134CTU
IC3514 (Not supplied) IC SII9134CTU
IC3515 6-708-913-01 IC TK73400AU3G0L-C
IC3516 6-705-337-01 IC TK11150CSCL-G
IC3517 6-708-913-01 IC TK73400AU3G0L-C
IC3518 8-759-058-62 IC TC7S08FU (TE85R)
IC3520 6-705-337-01 IC TK11150CSCL-G
IC3524 8-759-524-50 IC TC74VHC541FT (EL)
IC3525 8-759-679-36 IC TC7WT125FU (TE12R)
IC3526 8-759-596-39 IC SN74LV4052APWR
IC3601 6-709-545-01 IC FLI8668-LF-BC
IC3602 6-710-521-21 IC HY5DU561622FTP-4-C
IC3603 6-808-169-01 IC S29GL256N90TFIR20J08GUIX100
IC3604 6-709-564-01 IC YGV629-VZ
IC3605 6-708-913-01 IC TK73400AU3G0L-C
@ IC3606 6-711-139-01 IC FLI8638-LF
IC3607 6-710-521-21 IC HY5DU561622FTP-4-C
IC3608 6-702-300-01 IC TK11118CSCL-G
IC3609 6-707-842-01 IC TC74LCX08FT (EKJ)
IC3610 A-1566-608-A IC MB91F467RAPMC-GE1 (for SERVICE)
IC3611 6-710-003-01 IC IS61LV12816L-8TL
IC3612 6-708-913-01 IC TK73400AU3G0L-C
IC3613 6-702-300-01 IC TK11118CSCL-G
IC3614 6-702-302-01 IC TK11133CSCL-G
IC3615 6-808-310-03 IC SST39VF3202704IEKE54FLIM105
IC3616 6-702-302-01 IC TK11133CSCL-G
IC3617 6-708-913-01 IC TK73400AU3G0L-C
IC3618 6-710-521-21 IC HY5DU561622FTP-4-C
IC3619 6-710-050-01 IC TC74LCX245FK (EL)
IC3620 6-710-050-01 IC TC74LCX245FK (EL)
IC3621 6-704-573-01 IC M24C32-WMN6T (B)
IC3622 6-704-470-01 IC TK11233CMCL-G
IC3623 6-706-136-01 IC LTC3412EFE#TR
IC3624 6-710-521-21 IC HY5DU561622FTP-4-C
IC3625 6-704-470-01 IC TK11233CMCL-G
IC3626 6-702-302-01 IC TK11133CSCL-G
IC3627 6-808-311-03 IC SST39VF3202704IEKE54FLIZ106
IC3628 6-704-573-01 IC M24C32-WMN6T (B)
IC3629 6-702-302-01 IC TK11133CSCL-G
IC3850 6-709-565-01 IC ADV7322KSTZ
IC3851 6-704-261-01 IC TK11225CMCL-G
IC3852 6-702-301-01 IC TK11125CSCL-G
IC3853 6-712-613-01 IC SI-3010KM-TLS
IC3854 6-710-444-01 IC CY2302-SXC-1T
IC3855 6-709-565-01 IC ADV7322KSTZ
IC3856 6-704-261-01 IC TK11225CMCL-G
IC3857 6-710-444-01 IC CY2302-SXC-1T
IC3858 6-713-146-01 IC SN74CB3Q16211DGVR
IC3859 6-712-738-01 IC SN74CB3Q16210DGVR
IC3860 6-702-302-01 IC TK11133CSCL-G
IC3862 6-710-628-01 IC CY23EP05SXC-1HT
IC3863 6-710-628-01 IC CY23EP05SXC-1HT
* IC3864 6-711-583-01 IC TS3USB221RSER
< COIL >
L3501 1-469-525-91 INDUCT
OR 10uH
L3505 1-469-525-91 INDUCTOR 10uH
L3506 1-469-525-91 INDUCTOR 10uH
L3507 1-469-525-91 INDUCTOR 10uH
L3508 1-469-525-91 INDUCTOR 10uH
L3509 1-469-525-91 INDUCTOR 10uH
L3510 1-469-525-91 INDUCTOR 10uH
L3511 1-469-525-91 INDUCTOR 10uH
L3512 1-469-525-91 INDUCTOR 10uH
L3513 1-469-525-91 INDUCTOR 10uH
L3514 1-469-525-91 INDUCTOR 10uH
L3601 1-457-620-11 COIL, CHOKE 0.68uH
L3609 1-412-977-31 INDUCTOR 0.68uH
L3610 1-412-977-31 INDUCTOR 0.68uH
L3611 1-412-977-31 INDUCTOR 0.68uH
L3612 1-412-977-31 INDUCTOR 0.68uH
L3613 1-412-977-31 INDUCTOR 0.68uH
L3614 1-412-977-31 INDUCTOR 0.68uH
L3615 1-412-977-31 INDUCTOR 0.68uH
L3616 1-412-977-31 INDUCTOR 0.68uH
L3617 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q001 8-729-230-49 TRANSISTOR 2SC2712-YG
Q002 8-729-230-49 TRANSISTOR 2SC2712-YG
Q3500 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q3501 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
< RESISTOR >
R2038 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3001 1-216-864-11 SHORT CHIP 0
R3003 1-216-864-11 SHORT CHIP 0
R3004 1-216-864-11 SHORT CHIP 0
R3006 1-216-864-11 SHORT CHIP 0
R3007 1-216-864-11 SHORT CHIP 0
R3009 1-216-864-11 SHORT CHIP 0
R3013 1-216-864-11 SHORT CHIP 0
R3015 1-216-864-11 SHORT CHIP 0
R3016 1-216-864-11 SHORT CHIP 0
R3018 1-216-864-11 SHORT CHIP 0
R3019 1-216-864-11 SHORT CHIP 0
R3021 1-216-864-11 SHORT CHIP 0
R3025 1-216-864-11 SHORT CHIP 0
R3027 1-216-864-11 SHORT CHIP 0
R3028 1-216-864-11 SHORT CHIP 0
R3030 1-216-864-11 SHORT CHIP 0
R3031 1-216-864-11 SHORT CHIP 0
R3033 1-216-864-11 SHORT CHIP 0
D VIDEO
Note: IC3511, IC3513 and IC3514 cannot exchange with sin-
gle. When these parts are damaged, exchange the entire
mounted board.
@ Replacement of IC3606 used in this set requires a special
tool.
