Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA5400ES
212
MAIN VOL BOARD
**************
< CONNECTOR >
* CN712 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
< ROTARY ENCODER >
S722 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
************************************************************
MIC BOARD
*********
< CAPACITOR >
C755 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
< CONNECTOR >
CN718 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D717 6-501-817-01 DIODE MA2J1110GLS0
D718 6-501-817-01 DIODE MA2J1110GLS0
< JACK >
J701 1-820-056-11 SMALL TYPE JACK (AUTO CAL MIC)
< LEAD >
W701 1-775-377-21 LEAD (WITH CONNECTOR)
************************************************************
A-1530-376-A POWER AMP BOARD, COMPLETE
***************************
< CAPACITOR >
C1512 1-107-597-11 CERAMIC 22PF 5% 500V
C1513 1-107-597-11 CERAMIC 22PF 5% 500V
C1562 1-107-597-11 CERAMIC 22PF 5% 500V
C1563 1-107-597-11 CERAMIC 22PF 5% 500V
C1612 1-107-597-11 CERAMIC 22PF 5% 500V
C1613 1-107-597-11 CERAMIC 22PF 5% 500V
C1712 1-107-597-11 CERAMIC 22PF 5% 500V
C1713 1-107-597-11 CERAMIC 22PF 5% 500V
C1762 1-107-597-11 CERAMIC 22PF 5% 500V
C1763 1-107-597-11 CERAMIC 22PF 5% 500V
C1812 1-107-597-11 CERAMIC 22PF 5% 500V
C1813 1-107-597-11 CERAMIC 22PF 5% 500V
C1862 1-107-597-11 CERAMIC 22PF 5% 500V
C1863 1-107-597-11 CERAMIC 22PF 5% 500V
C1903 1-128-563-11 ELECT 100uF 20% 100V
C1904 1-128-563-11 ELECT 100uF 20% 100V
< CONNECTOR >
CN1510 1-573-846-11 CONNECTOR, BOARD TO BOARD 14P
CN1572 1-766-600-21 CONNECTOR, BOARD TO BOARD 7P
CN1703 1-573-846-11 CONNECTOR, BOARD TO BOARD 14P
CN1872 1-573-846-11 CONNECTOR, BOARD TO BOARD 14P
CN1903 1-573-844-11 CONNECTOR, BOARD TO BOARD 12P
CN1904 1-573-844-11 CONNECTOR, BOARD TO BOARD 12P
< COIL >
L1501 1-420-872-52 COIL, AIR-CORE
L1551 1-420-872-52 COIL, AIR-CORE
L1601 1-420-872-52 COIL, AIR-CORE
L1701 1-420-872-52 COIL, AIR-CORE
L1751 1-420-872-52 COIL, AIR-CORE
L1801 1-420-872-52 COIL, AIR-CORE
L1851 1-420-872-52 COIL, AIR-CORE
< RESISTOR >
0 R1515 1-249-405-91 CARBON 100 5% 1/4W F
0 R1516 1-234-572-21 ENCAPSULATED COMPONENT 0.22 5W F
0 R1517 1-249-405-91 CARBON 100 5% 1/4W F
0 R1518 1-249-393-91 CARBON 10 5% 1/4W F
0 R1565 1-249-405-91 CARBON 100 5% 1/4W F
0 R1566 1-234-572-21 ENCAPSULATED COMPONENT 0.22 5W F
0 R1567 1-249-405-91 CARBON 100 5% 1/4W F
0 R1568 1-249-393-91 CARBON 10 5% 1/4W F
0 R1615 1-249-405-91 CARBON 100 5% 1/4W F
0 R1616 1-234-572-21 ENCAPSULATED COMPONENT 0.22 5W F
0 R1617 1-249-405-91 CARBON 100 5% 1/4W F
0 R1618 1-249-393-91 CARBON 10 5% 1/4W F
0 R1715 1-249-405-91 CARBON 100 5% 1/4W F
0 R1716 1-234-572-21 ENCAPSULATED COMPONENT 0.22 5W F
0 R1717 1-249-405-91 CARBON 100 5% 1/4W F
0 R1718 1-249-393-91 CARBON 10 5% 1/4W F
0 R1765 1-249-405-91 CARBON 100 5% 1/4W F
0 R1766 1-234-572-21 ENCAPSULATED COMPONENT 0.22 5W F
0 R1767 1-249-405-91 CARBON 100 5% 1/4W F
0 R1768 1-249-393-91 CARBON 10 5% 1/4W F
0 R1815 1-249-405-91 CARBON 100 5% 1/4W F
0 R1816 1-234-572-21 ENCAPSULATED COMPONENT 0.22 5W F
0 R1817 1-249-405-91 CARBON 100 5% 1/4W F
0 R1818 1-249-393-91 CARBON 10 5% 1/4W F
0 R1865 1-249-405-91 CARBON 100 5% 1/4W F
0 R1866 1-234-572-21 ENCAPSULATED COMPONENT 0.22 5W F
0 R1867 1-249-405-91 CARBON 100 5% 1/4W F
0 R1868 1-249-393-91 CARBON 10 5% 1/4W F
************************************************************
A-1530-381-A PROTECTOR (F-C) BOARD, COMPLETE
*******************************
< CAPACITOR >
C1522 1-128-813-11 CERAMIC 220PF 5% 50V
C1523 1-136-153-00 MYLAR 0.01uF 5% 50V
C1524 1-126-964-11 ELECT 10uF 20% 50V
C1572 1-128-813-11 CERAMIC 220PF 5% 50V
C1573 1-136-153-00 MYLAR 0.01uF 5% 50V
C1574 1-126-964-11 ELECT 10uF 20% 50V
C1622 1-128-813-11 CERAMIC 220PF 5% 50V
C1623 1-136-153-00 MYLAR 0.01uF 5% 50V
C1624 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN1501 1-766-715-21 CONNECTOR, BOARD TO BOARD 10P
* CN1503 1-774-876-21 CONNECTOR, BOARD TO BOARD 8P
* CN1521 1-573-828-11 CONNECTOR, BOARD TO BOARD 14P
* CN1561 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN1571
1-766-724-11 CONNECTOR, BOARD TO BOARD 7P
MAIN VOL MIC POWER AMP PROTECTOR (F-C)
