Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA5400ES
215215
< TERMINAL >
0 TM4101 1-780-404-11 TERMINAL BOARD (SP) (8P)(SPEAKERS
SURROUND/SURROUND BACK (ZONE 2))
************************************************************
TEMPERATURE DETECTION BOARD
****************************
< CAPACITOR >
C1909 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1910 1-135-800-11 CERAMIC 1uF 50V
C1913 1-135-800-11 CERAMIC 1uF 50V
< DIODE >
D1906 8-719-109-93 DIODE RD6.2ESB2
< IC >
0 IC1903 6-710-072-01 IC LM61CIZ/LFT2
0
IC1905 6-710-072-01 IC LM61CIZ/LFT2
< RESISTOR >
R1928 1-249-414-11 CARBON 560 5% 1/4W
************************************************************
VIDEO 3 BOARD
*************
< CAPACITOR >
C757 1-104-665-11 ELECT 100uF 20% 25V
C758 1-104-665-11 ELECT 100uF 20% 25V
C759 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C760 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C761 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C762 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C763 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C764 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C765 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C766 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C767 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C768 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C769 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
< CONNECTOR >
CN721 1-784-923-11 PIN, CONNECTOR 7P
CN723 1-779-978-11 PIN, CONNECTOR 3P
CN725 1-784-922-11 PIN, CONNECTOR 5P
CN728 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D713 6-501-817-01 DIODE MA2J1110GLS0
D714 6-501-817-01 DIODE MA2J1110GLS0
D715 6-501-817-01 DIODE MA2J1110GLS0
D716 6-501-817-01 DIODE MA2J1110GLS0
< EARTH TERMINAL >
* ET702 1-537-738-21 TERMINAL, EARTH
* ET703 1-537-738-21 TERMINAL, EARTH
< IC >
IC706 8-759-710-97 IC NJM4565M-D
IC707 6-600-219-01
IC GP1FM313RZ0F(VIDEO 2 IN/
PORTABLE AV IN DIGITAL (OPT))
< JACK >
J702 1-815-313-11
JACK (PHONES)
J703 1-770-571-11 JACK BLOCK, PIN (L TYPE) 3P (VIDEO 2 IN/
PORTABLE AV IN AUDIO/VIDEO)
< RESISTOR >
R762 1-216-025-11 METAL CHIP 100 5% 1/10W
R763 1-216-049-11 METAL CHIP 1K 5% 1/10W
R764 1-216-049-11 METAL CHIP 1K 5% 1/10W
R765 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R768 1-216-089-91 METAL CHIP 47K 5% 1/10W
R769 1-216-089-91 METAL CHIP 47K 5% 1/10W
R770 1-216-295-91 SHORT CHIP 0
R774 1-216-295-91 SHORT CHIP 0
R775 1-216-295-91 SHORT CHIP 0
R776 1-216-295-91 SHORT CHIP 0
R785 1-216-295-91 SHORT CHIP 0
*************************************************************
