136
GB
Reference Power Output in Stereo Mode
(4 ohms 1 kHz, THD
0.7%):
170 W + 170 W
Reference Power Output
(8 ohms 1 kHz, THD
0.7%):
FRONT
2)
: 170 W + 170 W
CENTER
2)
: 170 W
SURR
2)
: 170 W + 170 W
SURR BACK
2)
: 170 W +
170 W
Reference Power Output
(4 ohms 1 kHz, THD
0.7%):
FRONT
2)
: 170 W + 170 W
CENTER
2)
: 170 W
SURR
2)
: 170 W + 170 W
SURR BACK
2)
: 170 W +
170 W
1)
Depending on the sound field settings and the
source, there may be no sound output.
2)
Measured under the following conditions:
Frequency response
Inputs (Analog)
Inputs (Digital)
Outputs
EQUALIZER
FM tuner section
Tuning range 87.5 - 108.0 MHz
Antenna FM wire antenna
Antenna terminals 75 ohms, unbalanced
Sensitivity
Mono: 18.3 dBf, 2.2 µV/75 ohms
Stereo: 38.3 dBf, 22.5 µV/75 ohms
Usable sensitivity 11.2 dBf, 1 µV/75 ohms
S/N
Mono: 76 dB
Stereo: 70 dB
Harmonic distortion at 1 kHz
Mono: 0.3%
Stereo: 0.5%
Separation 45 dB at 1 kHz
Frequency response 30 Hz – 15 kHz, +0.5/–2
dB
Selectivity 60 dB at 400 kHz
AM tuner section
Tuning range
Models of area code UC:
530 – 1,710 kHz
3)
(With 10-kHz tuning scale)
531 – 1,710 kHz
3)
(With 9-kHz tuning scale)
Area code Power requirements
UC 120 V AC, 60 Hz
TW 110 V AC, 60 Hz
CEL 230 V AC, 50/60 Hz
KR 220 V AC, 60 Hz
CN 220 V AC, 50 Hz
PHONO RIAA equalization curve
± 0.5 dB
Power Amp Block 10 Hz – 50 kHz
± 3 dB (8 ohms)
PHONO Sensitivity: 2.5mV
Impedance: 50kohms
S/N: 86dB (A, 20 kHz
LPF)
MULTI CHANNEL
INPUT1/2, SA-CD/CD,
TAPE, MD/DAT, DVD,
TV/SAT, VIDEO1/2/3
Sensitivity: 150mV
Impedance: 50kohms
S/N: 96dB (A, 20 kHz
LPF)
SA-CD/CD, DVD
(Coaxial)
Impedance: 75ohms
S/N: 96dB (A, 20 kHz
LPF)
SA-CD/CD, DVD,
TV /SAT, MD /DAT,
VIDEO 3 (Optical)
S/N: 96 dB
(A, 20 kHz LPF)
TAP E , MD / DAT
(REC OUT),
VIDEO1/2 (AUDIO OUT)
Voltage:150mV
Impedance: 10kohms
FRONT L/R, CENTER,
SURROUND L/R,
SURROUND BACK L/R,
SUB WOOFER
Voltage: 2V
Impedance: 1kohms
Gain levels ±10 dB, 1 dB step
