137
GB
Additional Information
Models of other area codes:
531 – 1,602 kHz
(With 9-kHz tuning scale)
Antenna Loop antenna
Usable sensitivity 50 dB µ/m (at 1,000 kHz or
999 kHz)
S/N 54 dB (at 50 mV/m)
Harmonic distortion 0.5% (50 mV/m, 400 Hz)
Selectivity
At 9 kHz: 35 dB
At 10 kHz: 40 dB
3)
You can change the AM tuning scale to either 9
kHz or 10 kHz. After tuning in any AM station,
turn off the receiver. While holding down PRESET
TUNING + or TUNING +, press ?/1. All preset
stations will be erased when you change the tuning
scale. To reset the scale to 10 kHz (or 9 kHz),
repeat the procedure.
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
S-video: Y: 1 Vp-p, 75 ohms
C: 0.286 Vp-p, 75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p, 75 ohms
P
B
/C
B
/B-Y: 0.7 Vp-p, 75
ohms
P
R
/C
R
/R-Y: 0.7 Vp-p, 75
ohms
80 MHz HD Pass Through
(When PROGRESSIVE
OUT is set to “OFF”)
i.LINK section
Pin 4 pins
Transmission speed S200 (Maximum data
transmission speed 200
Mbps)
Transmission protocol
A/M transmission protocol
Format (input) Super Audio CD* (DSD
PLAIN)
2 channel linear PCM
(IEC-60958-3)
Sampling frequency: 44.1
kHz
* Conforms to the copy protection technology of
DTLA (Revision 1.3).
General
Power requirements
Power consumption
Power consumption (during standby mode)
1 W
AC outlets
Dimensions 430 × 175 × 470 mm
(17 × 7 × 18
5
/
8
in.)
including projecting parts
and controls
Mass (Approx.) 23.5 kg (51 lb. 13 oz.)
Supplied accessories
FM wire antenna (1)
AM loop antenna (1)
AC power cord (1)
Remote commander RM-AAE003 (1)
LR6 (size-AA) batteries (3)
Remote commander RM-US106A (1)
R6 (size-AA) batteries (2)
Design and specifications are subject to
change without notice.
Area code Power requirements
UC 120 V AC, 60 Hz
CEL 230 V AC, 50/60 Hz
TW 110 V AC, 60 Hz
KR 220 V AC, 60 Hz
CN 220 V AC, 50 Hz
Area code Power consumption
UC, CEL, TW, KR,
CN
250 W
UC 300 VA
Area code AC outlets
UC 2 switched, 120 W/1A MAX
CEL 1 switched, 100 W MAX
KR, TW, CN – (no AC outlet)
For details on the area code of the
component you are using, see page 4.
