20
STR-DA1ES/DB780
• Circuit Boards Location
DC 2 board
PRE/SPOUT board
S-VIDEO board
H.P board
DIGITAL boar
d
BIAS board
MUTING board
KEY board
POWER board
VIDEO board
VIDEO 3 board
V3-OPT board
AC board
VIDEO.AU board
TUNE
R
MAIN board
DISPLAY board
DC 1 board
PR 1 board
SEC 1 board
