Sony STR-DB780 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
69
STR-DA1ES/DB780
DIGITAL
C1102 1-128-840-11 ELECT 47uF 20% 16V
(DB780)
C1103 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1104 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1105 1-126-947-11 ELECT 47uF 20% 16V
(DA1ES)
C1105 1-128-840-11 ELECT 47uF 20% 16V
(DB780)
C1106 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1107 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1108 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1109 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C1110 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C1111 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1112 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1113 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1114 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C1115 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1116 1-126-935-11 ELECT 470uF 20% 10V
(DA1ES)
C1116 1-128-834-11 ELECT 470uF 20% 10V
(DB780)
C1117 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1118 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C1119 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)
C1119 1-128-858-11 ELECT 22uF 20% 50V
(DB780)
C1120 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1121 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1122 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1123 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1124 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1126 1-119-824-11 ELECT 10uF 20% 50V
(DB780)
C1126 1-126-964-11 ELECT 10uF 20% 50V
(DA1ES)
C1127 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1129 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C1130 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1131 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1202 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1203 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1204 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1205 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1206 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1207 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1209 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1210 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1211 1-126-935-11 ELECT 470uF 20% 10V
(DA1ES)
C1211 1-128-834-11 ELECT 470uF 20% 10V
(DB780)
C1212 1-126-935-11 ELECT 470uF 20% 10V
(DA1ES)
C1212 1-128-834-11 ELECT 470uF 20% 10V
(DB780)
C1213 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1214 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1216 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1218 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1219 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1220 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1221 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(DB780: AEP, UK)
C1227 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1229 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1230 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1231 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1309 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1310 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1311 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1312 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1501 1-106-347-00 MYLAR 1500PF 5% 200V
C1502 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)
C1502 1-128-858-11 ELECT 22uF 20% 50V
(DB780)
C1503 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1504 1-119-824-11 ELECT 10uF 20% 50V
(DB780)
C1504 1-126-964-11 ELECT 10uF 20% 50V
(DA1ES)
C1505 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1506 1-126-935-11 ELECT 470uF 20% 16V
(DA1ES)
C1506 1-127-720-11 ELECT 470uF 20% 16V
(DB780)
C1507 1-119-824-11 ELECT 10uF 20% 50V
(DB780)
C1507 1-126-964-11 ELECT 10uF 20% 50V
(DA1ES)
C1508 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1509 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1510 1-126-947-11 ELECT 47uF 20% 16V
(DA1ES)
C1510 1-128-840-11 ELECT 47uF 20% 16V
(DB780)
C1512 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C1513 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1514 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1515 1-119-824-11 ELECT 10uF 20% 50V
(DB780)
C1515 1-126-964-11 ELECT 10uF 20% 50V
(DA1ES)
C1523 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)
C1523 1-128-858-11 ELECT 22uF 20% 50V
(DB780)
C1524 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)
C1524 1-128-858-11 ELECT 22uF 20% 50V
(DB780)
C1525 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)
C1525 1-128-858-11 ELECT 22uF 20% 50V
(DB780)
C1526 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)

Sony STR-DB780 Specifications

General

Type	Stereo Receiver
Total Harmonic Distortion	0.09 %
Digital inputs	2 Optical, 1 Coaxial
Weight	10.5 kg
Video inputs	composite
Video outputs	1 composite, 1 S-Video
Output Power	100 Watts (8 Ohms, 20 Hz - 20 kHz, 0.09% THD)
Signal-to-Noise Ratio	96 dB (Line in)
Input Sensitivity	150 mV (Line in)
