Sony STR-DB780 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
76
STR-DA1ES/DB780
C510 1-128-809-11 CERAMIC 100PF 5% 50V
C511 1-107-597-11 CERAMIC 22PF 10% 500V
C512 1-107-597-11 CERAMIC 22PF 10% 500V
C514 1-136-161-00 MYLAR 0.047uF 5% 50V
C515 1-136-165-00 MYLAR 0.1uF 5% 50V
C518 1-126-933-11 ELECT 100uF 20% 16V
(DA1ES)
C518 1-127-718-11 ELECT 100uF 20% 16V
(DB780: SP, MY, TW, KR, CH)
C518 1-135-709-11 ELECT 100uF 16V
(DB780: AEP, UK)
C519 1-128-809-11 CERAMIC 100PF 5% 50V
C521 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)
C521 1-128-858-11 ELECT 22uF 20% 50V
(DB780: SP, MY, TW, KR, CH)
C521 1-135-744-11 ELECT 22uF 50V
(DB780: AEP, UK)
C551 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)
C551 1-128-858-11 ELECT 22uF 20% 50V
(DB780: SP, MY, TW, KR, CH)
C551 1-135-744-11 ELECT 22uF 50V
(DB780: AEP, UK)
C552 1-102-110-00 CERAMIC 220PF 10% 50V
C554 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)
C554 1-128-858-11 ELECT 22uF 20% 50V
(DB780: SP, MY, TW, KR, CH)
C554 1-135-744-11 ELECT 22uF 50V
(DB780: AEP, UK)
C555 1-102-110-00 CERAMIC 220PF 10% 50V
C556 1-102-233-00 CERAMIC 33PF 10% 500V
C557 1-128-809-11 CERAMIC 100PF 5% 50V
C558 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C559 1-126-934-11 ELECT 220uF 20% 10V
(DA1ES)
C559 1-128-832-11 ELECT 220uF 20% 10V
(DB780: SP, MY, TW, KR, CH)
C559 1-135-667-11 ELECT 220uF 10V
(DB780: AEP, UK)
C560 1-128-809-11 CERAMIC 100PF 5% 50V
C561 1-107-597-11 CERAMIC 22PF 10% 500V
C562 1-107-597-11 CERAMIC 22PF 10% 500V
C564 1-136-161-00 MYLAR 0.047uF 5% 50V
C565 1-136-165-00 MYLAR 0.1uF 5% 50V
C568 1-126-933-11 ELECT 100uF 20% 16V
(DA1ES)
C568 1-127-718-11 ELECT 100uF 20% 16V
(DB780: SP, MY, TW, KR, CH)
C568 1-135-709-11 ELECT 100uF 16V
(DB780: AEP, UK)
C571 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)
C571 1-128-858-11 ELECT 22uF 20% 50V
(DB780: SP, MY, TW, KR, CH)
C571 1-135-744-11 ELECT 22uF 50V
(DB780: AEP, UK)
C601 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)
C601 1-128-858-11 ELECT 22uF 20% 50V
(DB780: SP, MY, TW, KR, CH)
C601 1-135-744-11 ELECT 22uF 50V
(DB780: AEP, UK)
C602 1-102-110-00 CERAMIC 220PF 10% 50V
C603 1-119-824-11 ELECT 10uF 20% 50V
(DB780: SP, MY, TW, KR, CH)
C603 1-126-964-11 ELECT 10uF 20% 50V
(DA1ES)
C603 1-135-743-11 ELECT 10uF 50V
(DB780: AEP, UK)
C604 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)
C604 1-128-858-11 ELECT 22uF 20% 50V
(DB780: SP, MY, TW, KR, CH)
C604 1-135-744-11 ELECT 22uF 50V
(DB780: AEP, UK)
C605 1-102-110-00 CERAMIC 220PF 10% 50V
C606 1-102-233-00 CERAMIC 33PF 10% 500V
C607 1-128-809-11 CERAMIC 100PF 5% 50V
C608 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C609 1-126-934-11 ELECT 220uF 20% 10V
(DA1ES)
C609 1-128-832-11 ELECT 220uF 20% 10V
(DB780: SP, MY, TW, KR, CH)
C609 1-135-667-11 ELECT 220uF 10V
(DB780: AEP, UK)
C610 1-128-809-11 CERAMIC 100PF 5% 50V
C611 1-107-597-11 CERAMIC 22PF 10% 500V
C612 1-107-597-11 CERAMIC 22PF 10% 500V
C614 1-136-161-00 MYLAR 0.047uF 5% 50V
C615 1-136-165-00 MYLAR 0.1uF 5% 50V
C618 1-126-933-11 ELECT 100uF 20% 16V
(DA1ES)
C618 1-127-718-11 ELECT 100uF 20% 16V
(DB780: SP, MY, TW, KR, CH)
C618 1-135-709-11 ELECT 100uF 16V
(DB780: AEP, UK)
C619 1-128-809-11 CERAMIC 100PF 5% 50V
C621 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)
C621 1-128-858-11 ELECT 22uF 20% 50V
(DB780: SP, MY, TW, KR, CH)
C621 1-135-744-11 ELECT 22uF 50V
(DB780: AEP, UK)
C701 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)
C701 1-128-858-11 ELECT 22uF 20% 50V
(DB780: SP, MY, TW, KR, CH)
C701 1-135-744-11 ELECT 22uF 50V
(DB780: AEP, UK)
C702 1-102-110-00 CERAMIC 220PF 10% 50V
C703 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)
C703 1-128-858-11 ELECT 22uF 20% 50V
(DB780: SP, MY, TW, KR, CH)
C703 1-135-744-11 ELECT 22uF 50V
(DB780: AEP, UK)
C718 1-126-933-11 ELECT 100uF 20% 16V
(DA1ES)
C718 1-127-718-11 ELECT 100uF 20% 16V
(DB780: SP, MY, TW, KR, CH)
MAIN

Sony STR-DB780 Specifications

General

Type	Stereo Receiver
Total Harmonic Distortion	0.09 %
Digital inputs	2 Optical, 1 Coaxial
Weight	10.5 kg
Video inputs	composite
Video outputs	1 composite, 1 S-Video
Output Power	100 Watts (8 Ohms, 20 Hz - 20 kHz, 0.09% THD)
Signal-to-Noise Ratio	96 dB (Line in)
Input Sensitivity	150 mV (Line in)
