Sony STR-DB795 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
79
STR-DB795
R2403 1-259-416-61 CARBON 330 5% 1/6W
R2404 1-259-430-61 CARBON 1.2K 5% 1/6W
R2405 1-259-444-61 CARBON 4.7K 5% 1/6W
R2406 1-259-430-61 CARBON 1.2K 5% 1/6W
R2407 1-259-422-61 CARBON 560 5% 1/6W
R2408 1-259-440-61 CARBON 3.3K 5% 1/6W
R2409 1-249-681-31 CARBON 2.2K 5% 1/4W
R2410 1-249-715-31 CARBON 56K 5% 1/4W
R2411 1-259-476-61 CARBON 100K 5% 1/6W
R2412 1-259-476-61 CARBON 100K 5% 1/6W
0R2413 1-249-413-11 CARBON 470 5% 1/4W F
0R2414 1-249-406-11 CARBON 120 5% 1/4W F
0R2415 1-249-406-11 CARBON 120 5% 1/4W F
R2416 1-259-464-61 CARBON 33K 5% 1/6W
R2419 1-259-408-61 CARBON 150 5% 1/6W
R2501 1-259-428-61 CARBON 1K 5% 1/6W
R2502 1-259-470-61 CARBON 56K 5% 1/6W
R2503 1-259-416-61 CARBON 330 5% 1/6W
R2504 1-259-430-61 CARBON 1.2K 5% 1/6W
R2505 1-259-444-61 CARBON 4.7K 5% 1/6W
R2506 1-259-430-61 CARBON 1.2K 5% 1/6W
R2507 1-259-422-61 CARBON 560 5% 1/6W
R2508 1-259-440-61 CARBON 3.3K 5% 1/6W
R2509 1-249-681-31 CARBON 2.2K 5% 1/4W
R2510 1-249-715-31 CARBON 56K 5% 1/4W
R2511 1-259-476-61 CARBON 100K 5% 1/6W
R2512 1-259-476-61 CARBON 100K 5% 1/6W
0R2513 1-249-413-11 CARBON 470 5% 1/4W F
0R2514 1-249-406-11 CARBON 120 5% 1/4W F
0R2515 1-249-406-11 CARBON 120 5% 1/4W F
R2516 1-259-464-61 CARBON 33K 5% 1/6W
R2519 1-259-408-61 CARBON 150 5% 1/6W
0R2601 1-215-873-81 METAL OXIDE 4.7K 5% 1W F
0R2602 1-260-107-11 CARBON 4.7K 5% 1/2W F
0R2603 1-249-381-11 CARBON 1 5% 1/4W F
0R2604 1-249-381-11 CARBON 1 5% 1/4W F
R2605 1-259-420-61 CARBON 470 5% 1/6W
R2606 1-259-420-61 CARBON 470 5% 1/6W
R2607 1-259-480-61 CARBON 150K 5% 1/6W
R2610 1-259-452-61 CARBON 10K 5% 1/6W
************************************************************
1-863-051-11 AC BOARD
*********
1-533-399-31 FUSE HOLDER
< CAPACITOR >
C51 1-112-125-11 CAP, ELECT 2200uF
C52 1-136-287-11 FILM 0.0047uF 5% 100V
C53 1-137-465-11 MYLAR 0.056uF 5% 100V
C54 1-112-125-11 CAP, ELECT 2200uF
C55 1-112-140-11 CAP, ELECT 1uF
C56 1-128-817-11 CERAMIC 470PF 5% 50V
< CONNECTOR >
* CN1 1-565-792-11 PIN, CONNECTOR (3.96mm PITCH) 2P
CN2 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN51 1-778-227-41 CONNECTOR, BOARD TO BOARD 6P
< DIODE >
D51 8-719-991-33 DIODE 1SS133T-77
D52 8-719-991-33 DIODE 1SS133T-77
D53 8-719-991-33 DIODE 1SS133T-77
D54 8-719-210-21 DIODE 11EQS04
D55 8-719-210-21 DIODE 11EQS04
D56 8-719-210-21 DIODE 11EQS04
D57 8-719-210-21 DIODE 11EQS04
D58 6-500-522-11 DIODE 10EDB40-TA2B5
< TRANSISTOR >
Q51 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q52 8-729-201-53 TRANSISTOR 2SA1015-GR
Q53 8-729-116-02 TRANSISTOR BA1A4M-TP
Q54 8-729-119-79 TRANSISTOR 2SC2785-FEK
< RESISTOR >
0R2 1-249-381-11 CARBON 1 5% 1/4W F
R51 1-249-421-11 CARBON 2.2K 5% 1/4W
R52 1-249-429-11 CARBON 10K 5% 1/4W
R53 1-249-415-11 CARBON 680 5% 1/4W
R54 1-249-437-11 CARBON 47K 5% 1/4W
R55 1-249-435-11 CARBON 33K 5% 1/4W
R56 1-249-429-11 CARBON 10K 5% 1/4W
R57 1-249-429-11 CARBON 10K 5% 1/4W
R58 1-247-807-31 CARBON 100 5% 1/4W
< RELAY >
0RY1 1-755-541-11 RELAY
< TRANSFORMER >
0T2 1-437-311-11 TRANSFORMER, POWER (TW)
0T2 1-437-313-11 TRANSFORMER, POWER (EXCEPT TW)
************************************************************
A-1054-319-A AU-IN BOARD, COMPLETE
*********************
< CAPACITOR >
C101 1-127-880-11 CERAMIC 0.022uF 10% 50V
C102 1-127-880-11 CERAMIC 0.022uF 10% 50V
C103 1-127-880-11 CERAMIC 0.022uF 10% 50V
C104 1-127-880-11 CERAMIC 0.022uF 10% 50V
C105 1-127-880-11 CERAMIC 0.022uF 10% 50V
C106 1-127-880-11 CERAMIC 0.022uF 10% 50V
C107 1-128-825-11 CERAMIC 2200PF 5% 50V
C110 1-112-090-11 CAP, ELECT 100uF
C111 1-112-090-11 CAP, ELECT 100uF
C112 1-112-090-11 CAP, ELECT 100uF
C113 1-112-090-11 CAP, ELECT 100uF
C114 1-112-090-11 CAP, ELECT 100uF
C115 1-112-090-11 CAP, ELECT 100uF
C120 1-127-876-11 CERAMIC 0.01uF 10% 50V
C121 1-127-880-11 CERAMIC 0.022uF 10% 50V
C122 1-127-880-11 CERAMIC 0.022uF 10% 50V
C123 1-128-809-11 CERAMIC 100PF 5% 50V
AC
AU-INA CLASS
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.

Sony STR-DB795 Specifications

General

Dimensions (WxDxH)	430 x 401 x 161 mm
Power requirements	230V, 50/60Hz
Supported radio bands	FM, MW
Radio Data System (RDS)	Yes
I/O ports	5.1 Analogue Input - 1.0 Audio Input - 3.0 Audio Input Front - 1 AV, S-Video Audio Output - 1.0 Control A1 / A1 II Digital Input: coaxial - 1.0 Digital Input: optical - 4.0 Digital Output: optical - 1.0 Headphone Output Monitor Output (Picture): FBAS - 1.0 Monitor Output (Picture): S-Video - 1.0 Phono Input Speaker Selector A S-Video Input - 4.0 S-Video Output - 1.0 Video Input - 5.0 Video Output - 2.0
Connectivity technology	Wired
Frequency range	20 - 20000 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	290 W

Weight and Dimensions

Weight	12500 g
