Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
80
STR-DB795
C131 1-128-809-11 CERAMIC 100PF 5% 50V
C132 1-128-809-11 CERAMIC 100PF 5% 50V
C133 1-128-813-11 CERAMIC 220PF 5% 50V
C134 1-128-813-11 CERAMIC 220PF 5% 50V
C135 1-112-141-11 CAP, ELECT 2.2uF
C136 1-112-141-11 CAP, ELECT 2.2uF
C137 1-128-809-11 CERAMIC 100PF 5% 50V
C138 1-128-809-11 CERAMIC 100PF 5% 50V
C139 1-112-117-11 CAP, ELECT 220uF
C140 1-112-117-11 CAP, ELECT 220uF
C141 1-125-896-11 MYLAR 0.0091uF 5% 50V
C142 1-125-896-11 MYLAR 0.0091uF 5% 50V
C143 1-136-159-00 MYLAR 0.033uF 5% 50V
C144 1-136-159-00 MYLAR 0.033uF 5% 50V
C145 1-112-141-11 CAP, ELECT 2.2uF
C146 1-112-141-11 CAP, ELECT 2.2uF
C161 1-127-876-11 CERAMIC 0.01uF 10% 50V
C171 1-112-090-11 CAP, ELECT 100uF
C174 1-127-876-11 CERAMIC 0.01uF 10% 50V
C175 1-128-809-11 CERAMIC 100PF 5% 50V
C181 1-112-090-11 CAP, ELECT 100uF
< CONNECTOR >
CN102 1-764-867-41 CONNECTOR, BOARD TO BOARD 20P
CN103 1-764-867-41 CONNECTOR, BOARD TO BOARD 20P
CN104 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
< IC >
IC101 6-703-975-01 IC TC9274N-017
IC110 8-759-167-88 IC NJM4565D
IC111 8-759-167-88 IC NJM4565D
IC112 8-759-167-88 IC NJM4565D
IC131 8-759-636-74 IC M5218AP-22
IC171 8-759-167-88 IC NJM4565D
IC172 8-759-167-88 IC NJM4565D
IC173 8-759-590-10 IC TC9273F-012 (EL)
< JACK >
J101 1-779-599-11 JACK, PIN 6P
(ANALOG MULTI CH IN FRONT, SURR, CENTER, SUB WOOFER)
J131 1-695-188-31 JACK, PIN 4P
(ANALOG MD/TAPE OUT, SA-CD/CD IN)
J151 1-695-188-31 JACK, PIN 4P
(ANALOG PHONO IN, MD/TAPE IN)
< RESISTOR >
JW145 1-259-412-61 CARBON 220 5% 1/6W
JW146 1-259-412-61 CARBON 220 5% 1/6W
JW148 1-259-412-61 CARBON 220 5% 1/6W
JW154 1-259-412-61 CARBON 220 5% 1/6W
R101 1-259-428-61 CARBON 1K 5% 1/6W
R102 1-259-428-61 CARBON 1K 5% 1/6W
R103 1-259-428-61 CARBON 1K 5% 1/6W
R104 1-259-428-61 CARBON 1K 5% 1/6W
R105 1-259-428-61 CARBON 1K 5% 1/6W
R106 1-259-428-61 CARBON 1K 5% 1/6W
R110 1-259-468-61 CARBON 47K 5% 1/6W
R111 1-259-468-61 CARBON 47K 5% 1/6W
R112 1-259-468-61 CARBON 47K 5% 1/6W
R113 1-259-468-61 CARBON 47K 5% 1/6W
R114 1-259-468-61 CARBON 47K 5% 1/6W
R115 1-259-468-61 CARBON 47K 5% 1/6W
R119 1-259-428-61 CARBON 1K 5% 1/6W
R131 1-259-436-61 CARBON 2.2K 5% 1/6W
R132 1-259-436-61 CARBON 2.2K 5% 1/6W
R133 1-259-476-61 CARBON 100K 5% 1/6W
R134 1-259-476-61 CARBON 100K 5% 1/6W
R135 1-259-410-61 CARBON 180 5% 1/6W
R136 1-259-410-61 CARBON 180 5% 1/6W
R137 1-259-450-61 CARBON 8.2K 5% 1/6W
R138 1-259-450-61 CARBON 8.2K 5% 1/6W
R139 1-259-476-61 CARBON 100K 5% 1/6W
R140 1-259-476-61 CARBON 100K 5% 1/6W
R141 1-259-404-61 CARBON 100 5% 1/6W
R142 1-259-404-61 CARBON 100 5% 1/6W
R143 1-259-476-61 CARBON 100K 5% 1/6W
R144 1-259-476-61 CARBON 100K 5% 1/6W
R145 1-259-420-61 CARBON 470 5% 1/6W
R146 1-259-420-61 CARBON 470 5% 1/6W
R147 1-259-476-61 CARBON 100K 5% 1/6W
R148 1-259-476-61 CARBON 100K 5% 1/6W
R151 1-259-428-61 CARBON 1K 5% 1/6W
R152 1-259-428-61 CARBON 1K 5% 1/6W
R153 1-259-436-61 CARBON 2.2K 5% 1/6W
R154 1-259-436-61 CARBON 2.2K 5% 1/6W
R155 1-259-428-61 CARBON 1K 5% 1/6W
R156 1-259-428-61 CARBON 1K 5% 1/6W
R171 1-259-452-61 CARBON 10K 5% 1/6W
R172 1-259-456-61 CARBON 15K 5% 1/6W
R173 1-259-444-61 CARBON 4.7K 5% 1/6W
R174 1-259-456-61 CARBON 15K 5% 1/6W
R175 1-259-452-61 CARBON 10K 5% 1/6W
R176 1-259-452-61 CARBON 10K 5% 1/6W
R177 1-259-452-61 CARBON 10K 5% 1/6W
R178 1-259-428-61 CARBON 1K 5% 1/6W
R181 1-259-452-61 CARBON 10K 5% 1/6W
R182 1-259-456-61 CARBON 15K 5% 1/6W
R183 1-259-444-61 CARBON 4.7K 5% 1/6W
R184 1-259-456-61 CARBON 15K 5% 1/6W
R185 1-259-452-61 CARBON 10K 5% 1/6W
R186 1-259-452-61 CARBON 10K 5% 1/6W
R187 1-259-452-61 CARBON 10K 5% 1/6W
0R840 1-249-399-11 CARBON 33 5% 1/4W F
0R845 1-249-399-11 CARBON 33 5% 1/4W F
************************************************************
A-1054-326-A COMP-V BOARD, COMPLETE (EXCEPT TW, KR)
A-1070-813-A COMP-V BOARD, COMPLETE (TW, KR)
***********************
< CAPACITOR >
C352 1-127-888-11 CERAMIC 0.1uF 10% 50V
C353 1-112-129-11 CAP, ELECT 100uF
C354 1-127-888-11 CERAMIC 0.1uF 10% 50V
C355 1-112-139-11 CAP, ELECT 0.47uF
C356 1-127-876-11 CERAMIC 0.01uF 10% 50V
AU-IN
COMP-V
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.

Sony STR-DB795 Specifications

General

Dimensions (WxDxH)	430 x 401 x 161 mm
Power requirements	230V, 50/60Hz
Supported radio bands	FM, MW
Radio Data System (RDS)	Yes
I/O ports	5.1 Analogue Input - 1.0 Audio Input - 3.0 Audio Input Front - 1 AV, S-Video Audio Output - 1.0 Control A1 / A1 II Digital Input: coaxial - 1.0 Digital Input: optical - 4.0 Digital Output: optical - 1.0 Headphone Output Monitor Output (Picture): FBAS - 1.0 Monitor Output (Picture): S-Video - 1.0 Phono Input Speaker Selector A S-Video Input - 4.0 S-Video Output - 1.0 Video Input - 5.0 Video Output - 2.0
Connectivity technology	Wired
Frequency range	20 - 20000 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	290 W

Weight and Dimensions

Weight	12500 g
