Sony STR-DB795 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
81
STR-DB795
C357 1-127-876-11 CERAMIC 0.01uF 10% 50V
C360 1-128-818-11 CERAMIC 560PF 5% 50V
C361 1-128-816-11 CERAMIC 390PF 5% 50V
C362 1-112-119-11 CAP, ELECT 470uF
C363 1-128-801-11 CERAMIC 22PF 5% 50V
C364 1-162-201-31 CERAMIC 12PF 5% 50V
C365 1-112-128-11 CAP, ELECT 47uF
C366 1-127-888-11 CERAMIC 0.1uF 10% 50V
C367 1-127-876-11 CERAMIC 0.01uF 10% 50V
C368 1-112-142-11 CAP, ELECT 4.7uF
C369 1-130-495-00 MYLAR 0.1uF 5% 50V
C370 1-162-201-31 CERAMIC 12PF 5% 50V
C371 1-128-801-11 CERAMIC 22PF 5% 50V
C372 1-162-201-31 CERAMIC 12PF 5% 50V
C373 1-128-801-11 CERAMIC 22PF 5% 50V
C374 1-112-119-11 CAP, ELECT 470uF
C375 1-112-144-11 CAP, ELECT 22uF
C376 1-126-786-11 ELECT 47uF 20% 16V
C377 1-127-888-11 CERAMIC 0.1uF 10% 50V
C378 1-127-888-11 CERAMIC 0.1uF 10% 50V
C379 1-128-812-11 CERAMIC 180PF 5% 50V
C380 1-127-876-11 CERAMIC 0.01uF 10% 50V
C381 1-127-876-11 CERAMIC 0.01uF 10% 50V
C382 1-127-888-11 CERAMIC 0.1uF 10% 50V
C383 1-112-129-11 CAP, ELECT 100uF
C384 1-127-888-11 CERAMIC 0.1uF 10% 50V
C385 1-127-876-11 CERAMIC 0.01uF 10% 50V
C386 1-112-129-11 CAP, ELECT 100uF
C387 1-127-876-11 CERAMIC 0.01uF 10% 50V
C388 1-127-876-11 CERAMIC 0.01uF 10% 50V
C389 1-127-888-11 CERAMIC 0.1uF 10% 50V
C390 1-112-129-11 CAP, ELECT 100uF
C391 1-112-128-11 CAP, ELECT 47uF
C392 1-127-888-11 CERAMIC 0.1uF 10% 50V
C393 1-162-203-31 CERAMIC 15PF 5% 50V
C394 1-112-141-11 CAP, ELECT 2.2uF
C395 1-127-876-11 CERAMIC 0.01uF 10% 50V
C396 1-112-142-11 CAP, ELECT 4.7uF
C397 1-127-876-11 CERAMIC 0.01uF 10% 50V
C398 1-128-806-11 CERAMIC 56PF 5% 50V
C399 1-112-143-11 CAP, ELECT 10uF
< CONNECTOR >
CN351 1-573-843-11 CONNECTOR, BOARD TO BOARD 11P
< DIODE >
D351 8-719-991-33 DIODE 1SS133T-77
D352 8-719-991-33 DIODE 1SS133T-77
< FERRITE BEAD >
FB353 1-412-911-11 INDUCTOR, FERRITE BEAD
FB354 1-412-911-11 INDUCTOR, FERRITE BEAD
< IC >
IC370 6-701-597-01 IC TC90A69N
IC371 6-706-778-01 IC MM1093PFB (EXCEPT TW, KR)
IC371 8-759-826-19 IC MM1093NF (TW, KR)
IC372 6-803-031-01 IC NJM2268D
< JACK >
J351 1-817-726-11 JACK, PIN 9P
(COMPONENT VIDEO MONITOR OUT, DVD IN, TV/SAT IN)
< COIL >
L370 1-410-514-11 INDUCTOR 27uH
L371 1-410-514-11 INDUCTOR 27uH
L372 1-414-189-31 INDUCTOR 100uH
L373 1-414-189-31 INDUCTOR 100uH
L374 1-410-514-11 INDUCTOR 27uH
L375 1-410-330-21 INDUCTOR 22uH (EXCEPT TW, KR)
L375 1-410-515-11 INDUCTOR 33uH (TW, KR)
L376 1-414-189-31 INDUCTOR 100uH
L377 1-414-189-31 INDUCTOR 100uH
< TRANSISTOR >
Q351 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q352 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q370 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q371 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q372 8-729-119-79 TRANSISTOR 2SC2785-FEK
< RESISTOR >
R357 1-249-421-11 CARBON 2.2K 5% 1/4W
R358 1-249-429-11 CARBON 10K 5% 1/4W
R359 1-249-421-11 CARBON 2.2K 5% 1/4W
R360 1-249-429-11 CARBON 10K 5% 1/4W
R361 1-249-417-11 CARBON 1K 5% 1/4W
R362 1-249-417-11 CARBON 1K 5% 1/4W
R363 1-247-903-00 CARBON 1M 5% 1/4W
R365 1-247-807-31 CARBON 100 5% 1/4W
R366 1-247-807-31 CARBON 100 5% 1/4W
R367 1-249-429-11 CARBON 10K 5% 1/4W
R368 1-249-435-11 CARBON 33K 5% 1/4W
R369 1-249-435-11 CARBON 33K 5% 1/4W
R371 1-249-418-11 CARBON 1.2K 5% 1/4W
R372 1-249-416-11 CARBON 820 5% 1/4W
R373 1-249-416-11 CARBON 820 5% 1/4W
R374 1-247-903-00 CARBON 1M 5% 1/4W
R375 1-249-418-11 CARBON 1.2K 5% 1/4W
R376 1-249-417-11 CARBON 1K 5% 1/4W
R377 1-249-416-11 CARBON 820 5% 1/4W
R378 1-249-416-11 CARBON 820 5% 1/4W
R379 1-249-416-11 CARBON 820 5% 1/4W
R380 1-249-430-11 CARBON 12K 5% 1/4W
R381 1-249-430-11 CARBON 12K 5% 1/4W
R382 1-249-418-11 CARBON 1.2K 5% 1/4W
R383 1-249-417-11 CARBON 1K 5% 1/4W
R386 1-249-429-11 CARBON 10K 5% 1/4W
R387 1-249-429-11 CARBON 10K 5% 1/4W
R388 1-249-412-11 CARBON 390 5% 1/4W
R389 1-249-412-11 CARBON 390 5% 1/4W
R390 1-247-903-00 CARBON 1M 5% 1/4W
R391 1-249-431-11 CARBON 15K 5% 1/4W
R392 1-247-847-91 CARBON 4.7K 5% 1/4W
(EXCEPT TW, KR)
COMP-V

Sony STR-DB795 Specifications

General

Dimensions (WxDxH)	430 x 401 x 161 mm
Power requirements	230V, 50/60Hz
Supported radio bands	FM, MW
Radio Data System (RDS)	Yes
I/O ports	5.1 Analogue Input - 1.0 Audio Input - 3.0 Audio Input Front - 1 AV, S-Video Audio Output - 1.0 Control A1 / A1 II Digital Input: coaxial - 1.0 Digital Input: optical - 4.0 Digital Output: optical - 1.0 Headphone Output Monitor Output (Picture): FBAS - 1.0 Monitor Output (Picture): S-Video - 1.0 Phono Input Speaker Selector A S-Video Input - 4.0 S-Video Output - 1.0 Video Input - 5.0 Video Output - 2.0
Connectivity technology	Wired
Frequency range	20 - 20000 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	290 W

Weight and Dimensions

Weight	12500 g
