Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
91
STR-DB795
< RESISTOR >
R401 1-259-448-61 CARBON 6.8K 5% 1/6W
R402 1-259-428-61 CARBON 1K 5% 1/6W
R403 1-259-476-61 CARBON 100K 5% 1/6W
R404 1-259-428-61 CARBON 1K 5% 1/6W
R405 1-259-436-61 CARBON 2.2K 5% 1/6W
0R412 1-249-405-11 CARBON 100 5% 1/4W F
0R413 1-249-405-11 CARBON 100 5% 1/4W F
0R414 1-234-572-21 ENCAPSULATED COMPONENT
0.22 5W F
R415 1-259-468-61 CARBON 47K 5% 1/6W
R416 1-259-476-61 CARBON 100K 5% 1/6W
0R419 1-249-393-11 CARBON 10 5% 1/4W F
R431 1-259-420-61 CARBON 470 5% 1/6W
R432 1-259-436-61 CARBON 2.2K 5% 1/6W
0R435 1-240-855-11 CARBON 6.2K 5% 1/4W F
R436 1-259-444-61 CARBON 4.7K 5% 1/6W
R437 1-259-434-61 CARBON 1.8K 5% 1/6W
R438 1-259-472-61 CARBON 68K 5% 1/6W
R439 1-259-456-61 CARBON 15K 5% 1/6W
R443 1-259-468-61 CARBON 47K 5% 1/6W
R451 1-259-448-61 CARBON 6.8K 5% 1/6W
R455 1-259-436-61 CARBON 2.2K 5% 1/6W
R457 1-259-428-61 CARBON 1K 5% 1/6W
R458 1-259-476-61 CARBON 100K 5% 1/6W
0R462 1-249-405-11 CARBON 100 5% 1/4W F
0R463 1-249-405-11 CARBON 100 5% 1/4W F
0R464 1-234-572-21 ENCAPSULATED COMPONENT
0.22 5W F
R465 1-259-468-61 CARBON 47K 5% 1/6W
R466 1-259-476-61 CARBON 100K 5% 1/6W
0R469 1-249-393-11 CARBON 10 5% 1/4W F
R481 1-259-420-61 CARBON 470 5% 1/6W
R482 1-259-436-61 CARBON 2.2K 5% 1/6W
0R485 1-240-855-11 CARBON 6.2K 5% 1/4W F
R486 1-259-444-61 CARBON 4.7K 5% 1/6W
R487 1-259-434-61 CARBON 1.8K 5% 1/6W
R488 1-259-472-61 CARBON 68K 5% 1/6W
R489 1-259-456-61 CARBON 15K 5% 1/6W
R493 1-259-468-61 CARBON 47K 5% 1/6W
R501 1-259-448-61 CARBON 6.8K 5% 1/6W
R502 1-259-428-61 CARBON 1K 5% 1/6W
R503 1-259-476-61 CARBON 100K 5% 1/6W
R504 1-259-428-61 CARBON 1K 5% 1/6W
0R512 1-249-405-11 CARBON 100 5% 1/4W F
0R513 1-249-405-11 CARBON 100 5% 1/4W F
0R514 1-234-572-21 ENCAPSULATED COMPONENT
0.22 5W F
R515 1-259-468-61 CARBON 47K 5% 1/6W
R516 1-259-476-61 CARBON 100K 5% 1/6W
0R519 1-249-393-11 CARBON 10 5% 1/4W F
R531 1-259-420-61 CARBON 470 5% 1/6W
R532 1-259-436-61 CARBON 2.2K 5% 1/6W
0R535 1-240-855-11 CARBON 6.2K 5% 1/4W F
R536 1-259-444-61 CARBON 4.7K 5% 1/6W
R537 1-259-434-61 CARBON 1.8K 5% 1/6W
R538 1-259-472-61 CARBON 68K 5% 1/6W
R539 1-259-456-61 CARBON 15K 5% 1/6W
R543 1-259-468-61 CARBON 47K 5% 1/6W
R551 1-259-448-61 CARBON 6.8K 5% 1/6W
R552 1-259-428-61 CARBON 1K 5% 1/6W
R553 1-259-476-61 CARBON 100K 5% 1/6W
0R562 1-249-405-11 CARBON 100 5% 1/4W F
0R563 1-249-405-11 CARBON 100 5% 1/4W F
0R564 1-234-572-21 ENCAPSULATED COMPONENT
0.22 5W F
R565 1-259-468-61 CARBON 47K 5% 1/6W
R566 1-259-476-61 CARBON 100K 5% 1/6W
0R569 1-249-393-11 CARBON 10 5% 1/4W F
R581 1-259-420-61 CARBON 470 5% 1/6W
R582 1-259-436-61 CARBON 2.2K 5% 1/6W
0R585 1-240-855-11 CARBON 6.2K 5% 1/4W F
R586 1-259-444-61 CARBON 4.7K 5% 1/6W
R587 1-259-434-61 CARBON 1.8K 5% 1/6W
R588 1-259-472-61 CARBON 68K 5% 1/6W
R589 1-259-456-61 CARBON 15K 5% 1/6W
R593 1-259-468-61 CARBON 47K 5% 1/6W
R601 1-259-448-61 CARBON 6.8K 5% 1/6W
R602 1-259-428-61 CARBON 1K 5% 1/6W
R603 1-259-476-61 CARBON 100K 5% 1/6W
R604 1-259-428-61 CARBON 1K 5% 1/6W
0R612 1-249-405-11 CARBON 100 5% 1/4W F
0R613 1-249-405-11 CARBON 100 5% 1/4W F
0R614 1-234-572-21 ENCAPSULATED COMPONENT
0.22 5W F
R615 1-259-468-61 CARBON 47K 5% 1/6W
R616 1-259-476-61 CARBON 100K 5% 1/6W
0R619 1-249-393-11 CARBON 10 5% 1/4W F
R631 1-259-420-61 CARBON 470 5% 1/6W
R632 1-259-436-61 CARBON 2.2K 5% 1/6W
0R635 1-240-855-11 CARBON 6.2K 5% 1/4W F
R636 1-259-444-61 CARBON 4.7K 5% 1/6W
R637 1-259-434-61 CARBON 1.8K 5% 1/6W
R638 1-259-472-61 CARBON 68K 5% 1/6W
R639 1-259-456-61 CARBON 15K 5% 1/6W
R643 1-259-468-61 CARBON 47K 5% 1/6W
R651 1-259-448-61 CARBON 6.8K 5% 1/6W
R652 1-259-428-61 CARBON 1K 5% 1/6W
R653 1-259-476-61 CARBON 100K 5% 1/6W
R654 1-259-428-61 CARBON 1K 5% 1/6W
0R662 1-249-405-11 CARBON 100 5% 1/4W F
0R663 1-249-405-11 CARBON 100 5% 1/4W F
0R664 1-234-572-21 ENCAPSULATED COMPONENT
0.22 5W F
R665 1-259-468-61 CARBON 47K 5% 1/6W
R666 1-259-476-61 CARBON 100K 5% 1/6W
0R669 1-249-393-11 CARBON 10 5% 1/4W F
R681 1-259-420-61 CARBON 470 5% 1/6W
R682 1-259-436-61 CARBON 2.2K 5% 1/6W
0R685 1-240-855-11 CARBON 6.2K 5% 1/4W F
R686 1-259-444-61 CARBON 4.7K 5% 1/6W
R687 1-259-434-61 CARBON 1.8K 5% 1/6W
R688 1-259-472-61 CARBON 68K 5% 1/6W
R689 1-259-456-61 CARBON 15K 5% 1/6W
R693 1-259-468-61 CARBON 47K 5% 1/6W
R701 1-259-448-61 CARBON 6.8K 5% 1/6W
MAIN
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
