Sony STR-DB795 - Page 92

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
92
STR-DB795
R702 1-259-428-61 CARBON 1K 5% 1/6W
R703 1-259-476-61 CARBON 100K 5% 1/6W
R715 1-259-468-61 CARBON 47K 5% 1/6W
R716 1-259-476-61 CARBON 100K 5% 1/6W
0R719 1-249-393-11 CARBON 10 5% 1/4W F
R738 1-259-472-61 CARBON 68K 5% 1/6W
R739 1-259-456-61 CARBON 15K 5% 1/6W
R743 1-259-468-61 CARBON 47K 5% 1/6W
R751 1-259-448-61 CARBON 6.8K 5% 1/6W
R752 1-259-428-61 CARBON 1K 5% 1/6W
R753 1-259-476-61 CARBON 100K 5% 1/6W
R782 1-259-476-61 CARBON 100K 5% 1/6W
R802 1-259-428-61 CARBON 1K 5% 1/6W
R805 1-259-452-61 CARBON 10K 5% 1/6W
R806 1-259-460-61 CARBON 22K 5% 1/6W
R807 1-259-452-61 CARBON 10K 5% 1/6W
R811 1-259-452-61 CARBON 10K 5% 1/6W
R812 1-259-436-61 CARBON 2.2K 5% 1/6W
R813 1-259-436-61 CARBON 2.2K 5% 1/6W
R814 1-259-436-61 CARBON 2.2K 5% 1/6W
R815 1-259-452-61 CARBON 10K 5% 1/6W
R816 1-259-452-61 CARBON 10K 5% 1/6W
R817 1-259-452-61 CARBON 10K 5% 1/6W
R818 1-259-452-61 CARBON 10K 5% 1/6W
R820 1-259-436-61 CARBON 2.2K 5% 1/6W
R821 1-259-452-61 CARBON 10K 5% 1/6W
0R824 1-215-867-00 METAL OXIDE 470 5% 1W F
0R825 1-215-867-00 METAL OXIDE 470 5% 1W F
R826 1-259-500-61 CARBON 1M 5% 1/6W
R827 1-259-428-61 CARBON 1K 5% 1/6W
R828 1-259-444-61 CARBON 4.7K 5% 1/6W
0R829 1-249-393-11 CARBON 10 5% 1/4W F
R830 1-259-428-61 CARBON 1K 5% 1/6W
R833 1-259-500-61 CARBON 1M 5% 1/6W
R838 1-259-436-61 CARBON 2.2K 5% 1/6W
R839 1-259-452-61 CARBON 10K 5% 1/6W
0R841 1-249-399-11 CARBON 33 5% 1/4W F
0R846 1-249-399-11 CARBON 33 5% 1/4W F
R847 1-259-436-61 CARBON 2.2K 5% 1/6W
R848 1-259-452-61 CARBON 10K 5% 1/6W
0R849 1-249-393-11 CARBON 10 5% 1/4W F
R850 1-259-452-61 CARBON 10K 5% 1/6W
R851 1-259-448-61 CARBON 6.8K 5% 1/6W
R852 1-259-460-61 CARBON 22K 5% 1/6W
R853 1-259-460-61 CARBON 22K 5% 1/6W
< VARIABLE RESISTOR >
RV431 1-238-595-11 RES, ADJ, CARBON 220
RV481 1-238-595-11 RES, ADJ, CARBON 220
RV531 1-238-595-11 RES, ADJ, CARBON 220
RV581 1-238-595-11 RES, ADJ, CARBON 220
RV631 1-238-595-11 RES, ADJ, CARBON 220
RV681 1-238-595-11 RES, ADJ, CARBON 220
< RELAY >
RY806 1-515-920-11 RELAY (24V)
RY807 1-755-483-11 RELAY
************************************************************
1-689-173-11 PRI BOARD
*********
< CONNECTOR >
* CN3 1-565-792-11 PIN, CONNECTOR (3.96mm PITCH) 2P
************************************************************
A-1054-419-A SBL BOARD, COMPLETE
********************
< CAPACITOR >
C731 1-112-128-11 CAP, ELECT 47uF
C732 1-128-813-11 CERAMIC 220PF 5% 50V
C2701 1-137-505-11 FILM 220PF 5% 100V
C2702 1-112-103-11 CAP, ELECT 47uF
C2704 1-112-122-11 CAP, ELECT 220uF
C2705 1-112-131-11 CAP, ELECT 330uF
C2706 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C2707 1-102-233-00 CERAMIC 33PF 10% 500V
C2708 1-137-383-11 MYLAR 220PF 5% 100V
C2807 1-137-389-11 MYLAR 0.0022uF 5% 100V
C2808 1-137-389-11 MYLAR 0.0022uF 5% 100V
< CONNECTOR >
CN732 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
CN2701 1-778-227-41 CONNECTOR, BOARD TO BOARD 6P
CN2703 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
< DIODE >
D2701 8-719-109-89 DIODE RD5.6ESB2
< TRANSISTOR >
Q731 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q733 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q734 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q2701 8-729-045-15 TRANSISTOR 2SC5169-FG
Q2703 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q2704 8-729-199-22 TRANSISTOR 2SA992-FA
Q2705 8-729-021-74 TRANSISTOR 2SA949-OY
Q2706 8-729-021-73 TRANSISTOR 2SC2229-OY
< RESISTOR >
0R712 1-249-405-11 CARBON 100 5% 1/4W F
0R713 1-249-405-11 CARBON 100 5% 1/4W F
0R714 1-234-572-21 ENCAPSULATED COMPONENT
0.22 5W F
R731 1-259-420-61 CARBON 470 5% 1/6W
R732 1-259-436-61 CARBON 2.2K 5% 1/6W
0R735 1-240-855-11 CARBON 6.2K 5% 1/4W F
R736 1-259-444-61 CARBON 4.7K 5% 1/6W
R737 1-259-434-61 CARBON 1.8K 5% 1/6W
R2701 1-259-428-61 CARBON 1K 5% 1/6W
R2702 1-259-470-61 CARBON 56K 5% 1/6W
R2703 1-259-416-61 CARBON 330 5% 1/6W
R2704 1-259-430-61 CARBON 1.2K 5% 1/6W
MAIN PRI SBL
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
