Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
93
STR-DB795
R2705 1-259-444-61 CARBON 4.7K 5% 1/6W
R2706 1-259-430-61 CARBON 1.2K 5% 1/6W
R2707 1-259-422-61 CARBON 560 5% 1/6W
R2708 1-259-440-61 CARBON 3.3K 5% 1/6W
R2709 1-249-681-31 CARBON 2.2K 5% 1/4W
R2710 1-249-715-31 CARBON 56K 5% 1/4W
R2711 1-259-476-61 CARBON 100K 5% 1/6W
R2712 1-259-476-61 CARBON 100K 5% 1/6W
0R2713 1-249-413-11 CARBON 470 5% 1/4W F
0R2714 1-249-406-11 CARBON 120 5% 1/4W F
0R2715 1-249-406-11 CARBON 120 5% 1/4W F
R2716 1-259-464-61 CARBON 33K 5% 1/6W
R2719 1-259-408-61 CARBON 150 5% 1/6W
< VARIABLE RESISTOR >
RV731 1-238-595-11 RES, ADJ, CARBON 220
************************************************************
1-689-174-11 SEC (1) BOARD
*************
< CONNECTOR >
CN53 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
************************************************************
1-689-176-11 SEC (3) BOARD
*************
< CONNECTOR >
CN57 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CN58 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
************************************************************
1-863-052-11 SP-A BOARD
***********
< CAPACITOR >
C443 1-127-876-11 CERAMIC 0.01uF 10% 50V
C444 1-128-817-11 CERAMIC 470PF 5% 50V
C448 1-128-817-11 CERAMIC 470PF 5% 50V
C449 1-127-876-11 CERAMIC 0.01uF 10% 50V
C493 1-127-876-11 CERAMIC 0.01uF 10% 50V
C498 1-128-817-11 CERAMIC 470PF 5% 50V
C499 1-127-876-11 CERAMIC 0.01uF 10% 50V
C548 1-128-817-11 CERAMIC 470PF 5% 50V
C549 1-127-876-11 CERAMIC 0.01uF 10% 50V
C598 1-128-817-11 CERAMIC 470PF 5% 50V
C599 1-127-876-11 CERAMIC 0.01uF 10% 50V
C698 1-128-817-11 CERAMIC 470PF 5% 50V
< CONNECTOR >
CN447 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
CN448 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
* CN449 1-770-727-11 CONNECTOR, BOARD TO BOARD 8P
CN450 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
< DIODE >
D444 8-719-991-33 DIODE 1SS133T-77
D449 8-719-991-33 DIODE 1SS133T-77
D549 8-719-991-33 DIODE 1SS133T-77
< COIL >
L449 1-420-872-52 COIL, AIR-CORE
L499 1-420-872-52 COIL, AIR-CORE
L549 1-420-872-52 COIL, AIR-CORE
L599 1-420-872-52 COIL, AIR-CORE
< RESISTOR >
0R443 1-249-393-11 CARBON 10 5% 1/4W F
0R444 1-249-393-11 CARBON 10 5% 1/4W F
0R447 1-249-393-11 CARBON 10 5% 1/4W F
0R448 1-249-393-11 CARBON 10 5% 1/4W F
0R449 1-249-393-11 CARBON 10 5% 1/4W F
0R493 1-249-393-11 CARBON 10 5% 1/4W F
0R498 1-249-393-11 CARBON 10 5% 1/4W F
0R499 1-249-393-11 CARBON 10 5% 1/4W F
0R547 1-249-393-11 CARBON 10 5% 1/4W F
0R548 1-249-393-11 CARBON 10 5% 1/4W F
0R549 1-249-393-11 CARBON 10 5% 1/4W F
0R598 1-249-393-11 CARBON 10 5% 1/4W F
0R599 1-249-393-11 CARBON 10 5% 1/4W F
< RELAY >
RY444 1-515-920-11 RELAY (24V)
RY449 1-515-920-11 RELAY (24V)
RY549 1-515-920-11 RELAY (24V)
< TERMINAL >
TM449 1-780-033-21 TERMINAL BOARD (SP) (8P)
(SPEAKERS IMPEDANCE USE 4-16Ω FRONT B, SURR)
TM699 1-694-933-21 TERMINAL BOARD (SP) (4P)
(SPEAKERS IMPEDANCE USE 4-16Ω FRONT A)
************************************************************
1-863-053-11 SP-B BOARD
***********
< CAPACITOR >
C210 1-127-868-11 CERAMIC 2200PF 10% 50V
C494 1-128-817-11 CERAMIC 470PF 5% 50V
C648 1-128-817-11 CERAMIC 470PF 5% 50V
C649 1-127-876-11 CERAMIC 0.01uF 10% 50V
C699 1-127-876-11 CERAMIC 0.01uF 10% 50V
C748 1-128-817-11 CERAMIC 470PF 5% 50V
C749 1-127-876-11 CERAMIC 0.01uF 10% 50V
< CONNECTOR >
CN443 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
CN444 1-770-726-11 CONNECTOR, BOARD TO BOARD 6P
CN451 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
< DIODE >
D649 8-719-991-33 DIODE 1SS133T-77
D699 8-719-991-33 DIODE 1SS133T-77
< JACK >
J203 1-770-377-31 JACK, PIN 1P (SUB WOOFER AUDIO OUT)
SEC (1)SBL SEC (3) SP-BSP-A
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
