Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
94
STR-DB795
< COIL >
L649 1-420-872-52 COIL, AIR-CORE
L699 1-420-872-52 COIL, AIR-CORE
L749 1-420-872-52 COIL, AIR-CORE
< RESISTOR >
R209 1-249-417-11 CARBON 1K 5% 1/4W
0R647 1-249-393-11 CARBON 10 5% 1/4W F
0R648 1-249-393-11 CARBON 10 5% 1/4W F
0R649 1-249-393-11 CARBON 10 5% 1/4W F
0R697 1-249-393-11 CARBON 10 5% 1/4W F
0R698 1-249-393-11 CARBON 10 5% 1/4W F
0R699 1-249-393-11 CARBON 10 5% 1/4W F
0R748 1-249-393-11 CARBON 10 5% 1/4W F
0R749 1-249-393-11 CARBON 10 5% 1/4W F
< RELAY >
RY649 1-515-920-11 RELAY (24V)
RY699 1-515-920-11 RELAY (24V)
< TERMINAL >
TM444 1-780-038-11 TERMINAL BOARD (SP) (6P) (SPEAKERS
IMPEDANCE USE 4-16Ω CENTER, SURR BACK)
************************************************************
1-863-054-11 STAY 3 BOARD
************
< CONNECTOR >
CN2706 1-770-010-21 CONNECTOR, BOARD TO BOARD 4P
CN2707 1-770-010-21 CONNECTOR, BOARD TO BOARD 4P
************************************************************
1-863-050-11 STAY 4 BOARD
************
< CONNECTOR >
CN452 1-770-011-21 CONNECTOR, BOARD TO BOARD 4P
CN453 1-770-011-21 CONNECTOR, BOARD TO BOARD 4P
************************************************************
A-1054-327-A S-VIDEO BOARD, COMPLETE
***********************
< CAPACITOR >
C850 1-128-805-11 CERAMIC 47PF 5% 50V
C851 1-128-805-11 CERAMIC 47PF 5% 50V
C852 1-128-805-11 CERAMIC 47PF 5% 50V
C853 1-128-805-11 CERAMIC 47PF 5% 50V
C854 1-128-825-11 CERAMIC 2200PF 5% 50V
C855 1-136-165-00 MYLAR 0.1uF 5% 50V
C856 1-136-165-00 MYLAR 0.1uF 5% 50V
C857 1-136-165-00 MYLAR 0.1uF 5% 50V
C858 1-112-143-11 CAP, ELECT 10uF
C859 1-112-143-11 CAP, ELECT 10uF
C860 1-112-143-11 CAP, ELECT 10uF
C861 1-128-825-11 CERAMIC 2200PF 5% 50V
C862 1-128-825-11 CERAMIC 2200PF 5% 50V
C863 1-127-888-11 CERAMIC 0.1uF 10% 50V
C864 1-136-165-00 MYLAR 0.1uF 5% 50V
C867 1-127-888-11 CERAMIC 0.1uF 10% 50V
C869 1-127-888-11 CERAMIC 0.1uF 10% 50V
C870 1-112-143-11 CAP, ELECT 10uF
C871 1-126-786-11 ELECT 47uF 20% 16V
C872 1-127-888-11 CERAMIC 0.1uF 10% 50V
C873 1-126-786-11 ELECT 47uF 20% 16V
C877 1-127-888-11 CERAMIC 0.1uF 10% 50V
C878 1-112-115-11 CAP, ELECT 1000uF
C879 1-112-140-11 CAP, ELECT 1uF
C890 1-112-121-11 CAP, ELECT 100uF
C2376 1-127-888-11 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
CN851 1-766-719-41 CONNECTOR, BOARD TO BOARD 10P
* CN853 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN854 1-573-825-11 CONNECTOR, BOARD TO BOARD 11P
CN1111 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D850 8-719-991-33 DIODE 1SS133T-77
D851 8-719-991-33 DIODE 1SS133T-77
D852 8-719-991-33 DIODE 1SS133T-77
D853 8-719-991-33 DIODE 1SS133T-77
< IC >
IC850 6-701-890-01 IC NJM2595D
IC851 6-701-890-01 IC NJM2595D
IC852 8-759-822-05 IC LA7213
< JACK >
J850 1-794-937-11 CONNECTOR (DIN) 2P
(VIDEO S-VIDEO DVD IN, TV/SAT IN)
J851 1-537-943-11 CONNECTOR (DIN) 1P
(VIDEO S-VIDEO MONITOR OUT)
J852 1-794-937-11 CONNECTOR (DIN) 2P
(VIDEO S-VIDEO VIDEO 1 IN/OUT)
J2305 1-563-330-31 JACK (CONTROL A1 II)
< TRANSISTOR >
Q850 8-729-030-02 TRANSISTOR DTC144ESA
Q851 8-729-201-53 TRANSISTOR 2SA1015-GR
< RESISTOR >
R854 1-247-804-11 CARBON 75 5% 1/4W
R855 1-247-804-11 CARBON 75 5% 1/4W
R856 1-247-804-11 CARBON 75 5% 1/4W
R857 1-247-804-11 CARBON 75 5% 1/4W
R858 1-247-804-11 CARBON 75 5% 1/4W
R859 1-247-804-11 CARBON 75 5% 1/4W
R860 1-247-804-11 CARBON 75 5% 1/4W
R861 1-247-804-11 CARBON 75 5% 1/4W
R862 1-247-804-11 CARBON 75 5% 1/4W
R863 1-247-804-11 CARBON 75 5% 1/4W
R864 1-247-883-00 CARBON 150K 5% 1/4W
R865 1-249-411-11 CARBON 330 5% 1/4W
R866 1-249-421-11 CARBON 2.2K 5% 1/4W
SP-B STAY 3 STAY 4 S-VIDEO
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
