Sony STR-DB795 - Page 95

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
95
STR-DB795
R867 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
RY850 1-755-359-11 RELAY
************************************************************
1-688-645-11 VIDEO BOARD
***********
< CAPACITOR >
C301 1-128-805-11 CERAMIC 47PF 5% 50V
C302 1-127-868-11 CERAMIC 2200PF 10% 50V
C303 1-112-143-11 CAP, ELECT 10uF
C304 1-127-868-11 CERAMIC 2200PF 10% 50V
C305 1-128-805-11 CERAMIC 47PF 5% 50V
C306 1-112-143-11 CAP, ELECT 10uF
C307 1-128-805-11 CERAMIC 47PF 5% 50V
C308 1-127-868-11 CERAMIC 2200PF 10% 50V
C309 1-112-143-11 CAP, ELECT 10uF
C310 1-112-143-11 CAP, ELECT 10uF
C311 1-127-888-11 CERAMIC 0.1uF 10% 50V
C313 1-112-143-11 CAP, ELECT 10uF
C315 1-127-888-11 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
CN301 1-766-719-41 CONNECTOR, BOARD TO BOARD 10P
< DIODE >
D301 8-719-991-33 DIODE 1SS133T-77
D302 8-719-991-33 DIODE 1SS133T-77
< IC >
IC301 6-701-890-01 IC NJM2595D
< JACK >
J302 1-794-970-11 JACK, PIN 1P (VIDEO MONITOR OUT)
J304 1-794-978-11 JACK, PIN 3P
(VIDEO VIDEO 1 IN/OUT, VIDEO 2 IN)
J305 1-794-978-11 JACK, PIN 3P
(VIDEO VIDEO 2 OUT, DVD IN, TV/SAT IN)
< RESISTOR >
R301 1-247-804-11 CARBON 75 5% 1/4W
R302 1-247-804-11 CARBON 75 5% 1/4W
R303 1-247-804-11 CARBON 75 5% 1/4W
R304 1-247-804-11 CARBON 75 5% 1/4W
R305 1-247-804-11 CARBON 75 5% 1/4W
R306 1-247-804-11 CARBON 75 5% 1/4W
R307 1-247-804-11 CARBON 75 5% 1/4W
************************************************************
VIDEO-AU BOARD
**************
< CAPACITOR >
C201 1-127-868-11 CERAMIC 2200PF 10% 50V
C211 1-127-880-11 CERAMIC 0.022uF 10% 50V
C212 1-127-880-11 CERAMIC 0.022uF 10% 50V
C213 1-128-809-11 CERAMIC 100PF 5% 50V
C214 1-127-876-11 CERAMIC 0.01uF 10% 50V
C215 1-127-868-11 CERAMIC 2200PF 10% 50V
< CONNECTOR >
CN201 1-766-719-41 CONNECTOR, BOARD TO BOARD 10P
* CN202 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< IC >
IC201 8-759-582-65 IC TC9273N-014
< JACK >
J201 1-774-411-11 JACK, PIN 6P
(VIDEO AUDIO VIDEO 2 OUT, DVD IN, TV/SAT IN)
J202 1-774-411-11 JACK, PIN 6P
(VIDEO AUDIO VIDEO 1 IN/OUT, VIDEO 2 IN)
< RESISTOR >
JW201 1-259-428-61 CARBON 1K 5% 1/6W
JW217 1-259-428-61 CARBON 1K 5% 1/6W
R201 1-259-428-61 CARBON 1K 5% 1/6W
R202 1-259-428-61 CARBON 1K 5% 1/6W
R203 1-259-436-61 CARBON 2.2K 5% 1/6W
R204 1-259-428-61 CARBON 1K 5% 1/6W
R205 1-259-436-61 CARBON 2.2K 5% 1/6W
R206 1-259-428-61 CARBON 1K 5% 1/6W
0R207 1-249-399-11 CARBON 33 5% 1/4W F
0R208 1-249-399-11 CARBON 33 5% 1/4W F
R211 1-259-428-61 CARBON 1K 5% 1/6W
R251 1-259-428-61 CARBON 1K 5% 1/6W
R252 1-259-428-61 CARBON 1K 5% 1/6W
R253 1-259-436-61 CARBON 2.2K 5% 1/6W
R254 1-259-428-61 CARBON 1K 5% 1/6W
R255 1-259-436-61 CARBON 2.2K 5% 1/6W
R256 1-259-428-61 CARBON 1K 5% 1/6W
************************************************************
VOL BOARD
**********
< CONNECTOR >
CN1060 1-779-978-11 PIN, CONNECTOR 3P
< ROTALY ENCODER >
RV1060 1-418-725-41 ENCODER, ROTARY (MASTER VOLUME)
************************************************************
MISCELLANEOUS
***************
053 1-696-847-22 CORD, POWER (AUS)
053 1-769-079-23 CORD, POWER (KR)
053 1-777-071-23 CORD, POWER (SP, MY)
053 1-827-597-41 CORD, POWER (TW)
053 1-829-626-11 CORD, POWER (AEP, UK)
108 1-769-938-11 WIRE (FLAT TYPE) (11 CORE)
(SP, MY, TW, KR, AUS)
108 1-773-002-11 WIRE (FLAT TYPE) (15 CORE) (AEP, UK)
VIDEO-AU VOLVIDEO
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
S-VIDEO
