– 86 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
TUNER
* 1-670-018-11 SP SW BOARD
***********
< CONNECTOR >
CNS106 1-770-404-11 HOUSING,CONNECTOR(PC BOARD)11P
< DIODE >
D120 8-719-911-19 DIODE 1SS119
D121 8-719-911-19 DIODE 1SS119
< RESISTOR >
R168 1-249-415-11 CARBON 680 5% 1/4W F
R169 1-249-417-11 CARBON 1K 5% 1/4W F
R170 1-249-419-11 CARBON 1.5K 5% 1/4W F
R172 1-249-421-11 CARBON 2.2K 5% 1/4W F
< SWITCH >
S105 1-762-751-11 SWITCH, TACTILE (SHIFT)
S131 1-762-751-11 SWITCH, TACTILE (1/u)
S132 1-762-751-11 SWITCH, TACTILE (DISPLAY)
S133 1-762-751-11 SWITCH, TACTILE (PRESET TUNING +)
S134 1-762-268-11 SWITCH, ROTARY (SPEAKERS)
S139 1-762-751-11 SWITCH, TACTILE (FM/AM)
S146 1-762-751-11 SWITCH, TACTILE (PRESET TUNING -)
**************************************************************
* 1-670-017-11 SW BOARD
********
< CAPACITOR >
C113 1-164-159-11 CERAMIC 0.1uF 50V
C114 1-164-159-11 CERAMIC 0.1uF 50V
C118 1-164-159-11 CERAMIC 0.1uF 50V
< DIODE >
D104 8-719-046-39 DIODE SEL5821A-TH15
D105 8-719-046-39 DIODE SEL5821A-TH15
D106 8-719-046-39 DIODE SEL5821A-TH15
< RESISTOR >
R124 1-249-411-11 CARBON 330 5% 1/4W
R136 1-249-413-11 CARBON 470 5% 1/4W F
R137 1-249-411-11 CARBON 330 5% 1/4W
R140 1-249-415-11 CARBON 680 5% 1/4W F
R144 1-249-417-11 CARBON 1K 5% 1/4W F
R148 1-249-419-11 CARBON 1.5K 5% 1/4W F
R152 1-249-421-11 CARBON 2.2K 5% 1/4W F
R156 1-249-425-11 CARBON 4.7K 5% 1/4W F
R166 1-249-411-11 CARBON 330 5% 1/4W
R167 1-249-413-11 CARBON 470 5% 1/4W F
R173 1-249-421-11 CARBON 2.2K 5% 1/4W F
R174 1-249-419-11 CARBON 1.5K 5% 1/4W F
R175 1-249-415-11 CARBON 680 5% 1/4W F
R176 1-249-413-11 CARBON 470 5% 1/4W F
R177 1-249-411-11 CARBON 330 5% 1/4W
R178 1-249-417-11 CARBON 1K 5% 1/4W F
< SWITCH >
S103 1-762-751-11 SWITCH, TACTILE (INPUT MODE)
S104 1-762-751-11 SWITCH, TACTILE (RDS-PTY)
S107 1-762-751-11 SWITCH, TACTILE (5.1 INPUT)
S108 1-762-751-11 SWITCH, TACTILE (RDS-EON)
S111 1-762-751-11 SWITCH, TACTILE (EQ ON/OFF)
S115 1-762-751-11 SWITCH, TACTILE (SOUND FIELD-GENRE)
S119 1-762-751-11 SWITCH, TACTILE (SOUND FIELD-MODE)
S123 1-762-751-11 SWITCH, TACTILE (SOUND FIELD-ON/OFF)
S135 1-762-751-11 SWITCH, TACTILE (<)
S136 1-762-751-11 SWITCH, TACTILE (∧)
S137 1-762-751-11 SWITCH, TACTILE (>)
S140 1-762-751-11 SWITCH, TACTILE (SET UP)
S141 1-762-751-11 SWITCH, TACTILE (CURSOR MODE)
S142 1-762-751-11 SWITCH, TACTILE (MEMORY)
S143 1-762-751-11 SWITCH, TACTILE (FM MODE)
S144 1-762-751-11 SWITCH, TACTILE (TUNING +)
S145 1-762-751-11 SWITCH, TACTILE (TUNING -)
S147 1-762-751-11 SWITCH, TACTILE (∨)
**************************************************************
* 1-670-000-11 TUNER BOARD
***********
< CAPACITOR >
C1 1-162-207-31 CERAMIC 22PF 5% 50V
C2 1-126-961-11 ELECT 2.2uF 20% 50V
C3 1-126-960-11 ELECT 1uF 20% 50V
C4 1-162-306-11 CERAMIC 0.01uF 20% 16V
C5 1-162-291-31 CERAMIC 560PF 10% 50V
C6 1-164-068-11 CERAMIC 82PF 5% 50V
C7 1-164-062-11 CERAMIC 47PF 5% 50V
C381 1-164-159-11 CERAMIC 0.1uF 50V
C382 1-161-494-00 CERAMIC 0.022uF 30% 25V
< CONNECTOR >
CNS304 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
CNS305 1-774-289-11 PIN, CONNECTOR (PC BOARD) 15P
< IC >
IC1 8-759-450-86 IC BU1922
< COIL >
L1 1-410-521-11 INDUCTOR 100uH
< RESISTOR >
R1 1-247-807-31 CARBON 100 5% 1/4W
R2 1-247-807-31 CARBON 100 5% 1/4W
R3 1-249-385-11 CARBON 2.2 5% 1/6W F
< VIBRATOR >
X1 1-579-900-21 VIBRATOR, CRYSTAL (4.33MHz)
**************************************************************
SWSP SW
