– 87 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* 1-670-003-11 VIDEO BOARD
***********
< CAPACITOR >
C201 1-126-964-11 ELECT 10uF 20% 50V
C202 1-126-964-11 ELECT 10uF 20% 50V
C203 1-126-964-11 ELECT 10uF 20% 50V
C204 1-126-964-11 ELECT 10uF 20% 50V
C205 1-162-215-31 CERAMIC 47PF 5% 50V
C206 1-162-215-31 CERAMIC 47PF 5% 50V
C207 1-162-215-31 CERAMIC 47PF 5% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C209 1-164-159-11 CERAMIC 0.1uF 50V
C210 1-164-159-11 CERAMIC 0.1uF 50V
C211 1-164-159-11 CERAMIC 0.1uF 50V
C212 1-164-159-11 CERAMIC 0.1uF 50V
C213 1-126-933-11 ELECT 100uF 20% 16V
C214 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
* CNS210 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CNS211 1-784-733-11 CONNECTOR, FFC 11P
CNS212 1-784-731-11 CONNECTOR, FFC 9P
< DIODE >
D201 8-719-911-19 DIODE 1SS119
D202 8-719-911-19 DIODE 1SS119
< IC >
IC201 8-759-529-20 IC NJM2296D
IC202 8-759-701-65 IC NJM79M05FA
< JACK >
J201 1-766-399-11 JACK, PIN 3P (VIDEO1 VIDEO OUT, VIDEO IN/
MONITOR VIDEO OUT)
J202 1-766-400-11 JACK, PIN 2P (VIDEO2 VIDEO OUT, VIDEO IN)
J203 1-766-400-11 JACK, PIN 2P (TV/LD VIDEO IN, DVD VIDEO IN)
J204 1-563-330-11 JACK (S-LINK CTRL A1)
< RESISTOR >
R201 1-247-804-11 CARBON 75 5% 1/4W
R202 1-247-804-11 CARBON 75 5% 1/4W
R203 1-247-804-11 CARBON 75 5% 1/4W
R204 1-247-804-11 CARBON 75 5% 1/4W
R205 1-247-804-11 CARBON 75 5% 1/4W
R206 1-247-804-11 CARBON 75 5% 1/4W
R207 1-247-804-11 CARBON 75 5% 1/4W
**************************************************************
* 1-670-019-11 VOLUME BOARD
************
< CAPACITOR >
C410 1-126-233-11 ELECT 22uF 20% 50V
C411 1-126-233-11 ELECT 22uF 20% 50V
C412 1-126-233-11 ELECT 22uF 20% 50V
C413 1-162-199-31 CERAMIC 10PF 5% 50V
C414 1-162-199-31 CERAMIC 10PF 5% 50V
C415 1-162-199-31 CERAMIC 10PF 5% 50V
C421 1-162-286-31 CERAMIC 220PF 10% 50V
C422 1-162-286-31 CERAMIC 220PF 10% 50V
C423 1-162-286-31 CERAMIC 220PF 10% 50V
C460 1-126-233-11 ELECT 22uF 20% 50V
C461 1-126-233-11 ELECT 22uF 20% 50V
C462 1-126-233-11 ELECT 22uF 20% 50V
C463 1-162-199-31 CERAMIC 10PF 5% 50V
C464 1-162-199-31 CERAMIC 10PF 5% 50V
C465 1-162-199-31 CERAMIC 10PF 5% 50V
C471 1-162-286-31 CERAMIC 220PF 10% 50V
C472 1-162-286-31 CERAMIC 220PF 10% 50V
C473 1-162-286-31 CERAMIC 220PF 10% 50V
< CONNECTOR >
CNP102 1-770-388-11 PIN, CONNECTOR (PC BOARD) 4P
CNP103 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
* CNS402 1-564-726-11 PIN, CONNECTOR (SMALL TYPE)10P
< IC >
IC408 8-759-634-50 IC M5218AL
IC409 8-759-634-50 IC M5218AL
IC410 8-759-634-50 IC M5218AL
< RESISTOR >
R110 1-249-411-11 CARBON 330 5% 1/4W
R413 1-249-437-11 CARBON 47K 5% 1/4W
R414 1-249-437-11 CARBON 47K 5% 1/4W
R415 1-249-437-11 CARBON 47K 5% 1/4W
R416 1-249-429-11 CARBON 10K 5% 1/4W
R417 1-247-843-11 CARBON 3.3K 5% 1/4W
R418 1-249-437-11 CARBON 47K 5% 1/4W
R419 1-249-437-11 CARBON 47K 5% 1/4W
R420 1-249-437-11 CARBON 47K 5% 1/4W
R421 1-249-437-11 CARBON 47K 5% 1/4W
R463 1-249-437-11 CARBON 47K 5% 1/4W
R464 1-249-437-11 CARBON 47K 5% 1/4W
R465 1-249-437-11 CARBON 47K 5% 1/4W
R466 1-249-429-11 CARBON 10K 5% 1/4W
R467 1-247-843-11 CARBON 3.3K 5% 1/4W
R468 1-247-843-11 CARBON 3.3K 5% 1/4W
R469 1-249-437-11 CARBON 47K 5% 1/4W
R470 1-249-437-11 CARBON 47K 5% 1/4W
R471 1-249-437-11 CARBON 47K 5% 1/4W
< VARIABLE RESISTOR >
RV401 1-225-445-11 RES, VAR, CARBON 100KX6 (MASTER VOLUME)
**************************************************************
MISCELLANEOUS
*************
6 1-769-904-11 WIRE (FLAT TYPE)(9 CORE)
8 1-693-409-11 TUNER
! 14 1-769-744-11 CORD, POWER
18 1-769-876-11 WIRE (FLAT TYPE)(7 CORE)
VOLUMEVIDEO
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
