– 88 –
STR-DB925
Ref. No. Part No. Description Remark
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
71 1-773-163-11 WIRE (FLAT TYPE)(21 CORE)
72 1-769-961-11 WIRE (FLAT TYPE)(11 CORE)
109 1-773-285-11 WIRE (FLAT TYPE)(29 CORE)
! CNJ909 1-526-794-11 OUTLET, AC
FL101 1-517-781-11 INDICATOR TUBE, FLUORESCENT
Q505 8-729-209-15 TRANSISTOR 2SD2012
Q506 8-749-010-25 IC MN2488-OPY-M
Q507 8-749-010-26 IC MP1620-OPY-M
Q555 8-729-209-15 TRANSISTOR 2SD2012
Q556 8-749-010-25 IC MN2488-OPY-M
Q557 8-749-010-26 IC MP1620-OPY-M
Q605 8-729-209-15 TRANSISTOR 2SD2012
Q606 8-749-010-25 IC MN2488-OPY-M
Q607 8-749-010-26 IC MP1620-OPY-M
Q705 8-729-209-15 TRANSISTOR 2SD2012
Q706 8-749-010-25 IC MN2488-OPY-M
Q707 8-749-010-26 IC MP1620-OPY-M
Q755 8-729-209-15 TRANSISTOR 2SD2012
Q756 8-749-010-25 IC MN2488-OPY-M
Q757 8-749-010-26 IC MP1620-OPY-M
! T901 1-431-889-11 TRANSFORMER, POWER
**************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-475-726-12 REMOTE COMMANDER (RM-LJ301)
1-501-374-11 ANTENNA, LOOP
3-864-441-11 MANUAL, INSTRUCTION (RM-LJ301)(ENGLISH)
3-864-441-21 MANUAL, INSTRUCTION (RM-LJ301)
(FRENCH,SPANISH)
3-864-441-41 MANUAL, INSTRUCTION (RM-LJ301)(DUTCH,
SWEDISH,GERMAN,ITALIAN,PORTUGUESE)
3-864-483-71 MANUAL, INSTRUCTION
(ENGLISH,FRENCH,DUTCH,SWEDISH)
3-864-483-81 MANUAL, INSTRUCTION
(GERMAN,SPANISH,ITALIAN,PORTUGUESE)
4-210-990-01 LID (RM-LJ301), BATTERY CASE (For RM-LJ301)
4-212-261-01 COVER (FRONT)(For RM-LJ301)
**************************************************************
*************
HARDWARE LIST
*************
#1 7-685-885-09 SCREW +BVTT 4X16 (S)
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#3 7-685-132-19 SCREW +BTP 2.6X5 TYPE2 N-S
Sony Corporation
Home A&V Products Company9-922-932-11
98G0953-1
Printed in Japan © 1998. 7
Published by Quality Assurance Dept.
(Shibaura)
