Sony STR-DE875 - Video Board Components

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
54
STR-DE875/DE975
C211 1-164-159-11 CERAMIC 0.1uF 50V
C212 1-126-960-11 ELECT 1uF 20.00% 50V
C213 1-164-159-11 CERAMIC 0.1uF 50V
C215 1-128-805-11 CERAMIC 47PF 5% 50V
C216 1-128-805-11 CERAMIC 47PF 5% 50V
C217 1-128-817-11 CERAMIC 470PF 5% 50V
C218 1-126-960-11 ELECT 1uF 20.00% 50V
C219 1-164-159-11 CERAMIC 0.1uF 50V
C220 1-128-817-11 CERAMIC 470PF 5% 50V
(DE875:US,CND,E/DE975)
C221 1-128-817-11 CERAMIC 470PF 5% 50V
(DE875:US,CND,E/DE975)
C222 1-126-947-11 ELECT 47uF 20.00% 35V
(DE875:US,CND,E/DE975)
C223 1-126-947-11 ELECT 47uF 20.00% 35V
(DE875:US,CND,E/DE975)
C224 1-164-159-11 CERAMIC 0.1uF 50V
C225 1-128-817-11 CERAMIC 470PF 5% 50V
CNS201 1-568-440-11 SOCKET, CONNECTOR 17P (DE975)
CNS201 1-569-442-11 JACK, PIN 2P (DE875)
CNS202 1-569-321-11 SOCKET, CONNECTOR 15P
< DIODE >
D201 8-719-911-19 DIODE 1SS133T-72
D202 8-719-911-19 DIODE 1SS133T-72
D203 8-719-118-63 DIODE RD5.6F-T7B2
< IC >
IC201 8-759-529-20 IC NJM2296D
IC202 8-759-529-20 IC NJM2296D
IC203 8-759-666-33 IC NJM2145D (DE875:US,CND,E/DE975)
< JACK >
J201 1-537-943-11 TERMINAL, S (MONITOR S-VIDEO OUT)
J202 1-764-676-11 CONNECTOR (ROUND TYPE)
(TV/SAT/DVD/LD S-VIDEO IN)
J203 1-764-676-11 CONNECTOR (ROUND TYPE)
(VIDEO1 S-VIDEO IN/OUT)
J204 1-563-330-11 JACK (CONTROL A1 II)
J205 1-563-330-11 JACK (VIDEO1 CTRL S OUT)
(DE875:US,CND,E/DE975)
J206 1-563-330-11 JACK (DVD/LD CTRL S OUT)
(DE875:US,CND,E/DE975)
J207 1-563-330-11 JACK (TV/SAT CTRL S STATUS IN)
(DE875:US,CND,E/DE975)
J208 1-563-330-11 JACK (MONITOR CTRL S IN)
(DE875:US,CND,E/DE975)
< TRANSISTOR >
Q201 8-729-422-57 TRANSISTOR BN1A4M-TP
(DE875:US,CND,E/DE975)
Q202 8-729-900-80 TRANSISTOR BA1A4M-TP
(DE875:US,CND,E/DE975)
< RESISTOR >
R201 1-247-804-11 CARBON 75 5% 1/4W
R202 1-247-804-11 CARBON 75 5% 1/4W
R203 1-247-804-11 CARBON 75 5% 1/4W
R204 1-247-804-11 CARBON 75 5% 1/4W
R205 1-247-804-11 CARBON 75 5% 1/4W
R206 1-247-804-11 CARBON 75 5% 1/4W
R207 1-247-804-11 CARBON 75 5% 1/4W
R208 1-247-804-11 CARBON 75 5% 1/4W
R209 1-247-804-11 CARBON 75 5% 1/4W
R210 1-247-804-11 CARBON 75 5% 1/4W
R211 1-249-429-11 CARBON 10K 5% 1/4W
R212 1-249-429-11 CARBON 10K 5% 1/4W
R213 1-249-429-11 CARBON 10K 5% 1/4W
R214 1-249-417-11 CARBON 1K 5% 1/4W F
(DE875:US,CND,E/DE975)
R215 1-249-417-11 CARBON 1K 5% 1/4W F
(DE875:US,CND,E/DE975)
R216 1-249-417-11 CARBON 1K 5% 1/4W F
(DE875:US,CND,E/DE975)
R217 1-249-417-11 CARBON 1K 5% 1/4W F
(DE875:US,CND,E/DE975)
R218 1-249-425-11 CARBON 4.7K 5% 1/4W F
R219 1-249-427-11 CARBON 6.8K 5% 1/4W F
R220 1-249-427-11 CARBON 6.8K 5% 1/4W F
************************************************************
A-4476-069-A VIDEO BOARD, COMPLETE (DE975)
*********************
A-4476-162-A VIDEO BOARD, COMPLETE (DE875)
*********************
< CAPACITOR >
C251 1-128-801-11 CERAMIC 22PF 5% 50V
(DE975)
C252 1-162-198-31 CERAMIC 8.2PF 10.00% 50V
(DE975)
C254 1-126-947-11 ELECT 47uF 20.00% 35V
(DE975)
C255 1-164-159-11 CERAMIC 0.1uF 50V
(DE975)
C256 1-128-803-11 CERAMIC 33PF 5% 50V
(DE975)
C257 1-162-199-31 CERAMIC 10PF 5% 50V
(DE975)
C258 1-164-159-11 CERAMIC 0.1uF 50V
(DE975)
C259 1-128-809-11 CERAMIC 100PF 5% 50V
(DE975)
C260 1-126-964-11 ELECT 10uF 20.00% 50V
(DE975)
C261 1-126-964-11 ELECT 10uF 20.00% 50V
(DE975)
S-VIDEO VIDEO
