Sony STR-DE875 - Video Board Components (Cont.)

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
55
STR-DE875/DE975
C262 1-126-960-11 ELECT 1uF 20.00% 50V
(DE975)
C263 1-126-935-11 ELECT 470uF 20.00% 10V
(DE975)
C264 1-126-935-11 ELECT 470uF 20.00% 10V
(DE975)
C265 1-126-964-11 ELECT 10uF 20.00% 50V
(DE975)
C266 1-126-964-11 ELECT 10uF 20.00% 50V
(DE975)
C267 1-126-964-11 ELECT 10uF 20.00% 50V
(DE975)
C268 1-126-964-11 ELECT 10uF 20.00% 50V
(DE975)
C269 1-164-159-11 CERAMIC 0.1uF 50V
(DE975)
C270 1-126-947-11 ELECT 47uF 20.00% 35V
(DE975)
C271 1-164-159-11 CERAMIC 0.1uF 50V
C272 1-126-947-11 ELECT 47uF 20.00% 35V
C275 1-126-964-11 ELECT 10uF 20.00% 50V
C277 1-128-805-11 CERAMIC 47PF 5% 50V
C280 1-164-159-11 CERAMIC 0.1uF 50V
C281 1-126-947-11 ELECT 47uF 20.00% 35V
C282 1-128-805-11 CERAMIC 47PF 5% 50V
C283 1-128-825-11 CERAMIC 2200PF 5% 50V
C284 1-126-964-11 ELECT 10uF 20.00% 50V
C285 1-128-825-11 CERAMIC 2200PF 5% 50V
C286 1-126-964-11 ELECT 10uF 20.00% 50V
C287 1-128-805-11 CERAMIC 47PF 5% 50V
C288 1-128-805-11 CERAMIC 47PF 5% 50V
C289 1-128-805-11 CERAMIC 47PF 5% 50V
C290 1-126-964-11 ELECT 10uF 20.00% 50V
C291 1-126-964-11 ELECT 10uF 20.00% 50V
C292 1-128-805-11 CERAMIC 47PF 5% 50V
C293 1-128-805-11 CERAMIC 47PF 5% 50V
C294 1-128-805-11 CERAMIC 47PF 5% 50V
C295 1-128-825-11 CERAMIC 2200PF 5% 50V
< CONNECTOR >
CNP251 1-564-506-11 PLUG, CONNECTOR 3P (DE975)
CNP252 1-569-321-11 SOCKET, CONNECTOR 15P (DE975)
CNP252 1-568-442-11 SOCKET, CONNECTOR 9P (DE875)
CNP253 1-784-921-11 PIN, CONNECTOR 4P (DE975)
CNP254 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< TRIMMER >
CT251 1-141-442-91 CAP, CERAMIC TRIMMER 20PF (DE975)
CT252 1-141-442-91 CAP, CERAMIC TRIMMER 20PF (DE975)
< DIODE >
D251 8-719-911-19 DIODE 1SS133T-72 (DE975)
D252 8-719-911-19 DIODE 1SS133T-72
D253 8-719-911-19 DIODE 1SS133T-72
< FERRITE BEAD >
FB251 1-416-300-21 FILTER, NOISE (DE975)
< IC >
IC251 8-759-529-20 IC NJM2296D
IC252 8-759-835-09 IC MB90089PF-G-237-BND (DE975)
IC253 8-759-666-34 IC BA7622 (DE975)
< JACK >
J251 1-774-227-11 JACK, PIN 1P (MONITOR VIDEO OUT)
J252 1-770-337-11 JACK, PIN 3P
(TV/SAT/DVD/LD VIDEO IN,VIDEO2 VIDEO OUT)
J253 1-770-337-11 JACK, PIN 3P
(VIDEO2 VIDEO IN,VIDEO1 VIDEO IN/OUT)
< COIL >
L251 1-410-973-11 INDUCTOR 22uH (DE975)
< TRANSISTOR >
Q203 8-729-119-79 TRANSISTOR 2SC2785TP-FEK (DE975)
Q204 8-729-119-79 TRANSISTOR 2SC2785TP-FEK (DE975)
< RESISTOR >
R251 1-249-410-11 CARBON 270 5% 1/4W F
(DE975)
R252 1-249-425-11 CARBON 4.7K 5% 1/4W F
(DE975)
R253 1-249-417-11 CARBON 1K 5% 1/4W F
(DE975)
R254 1-249-417-11 CARBON 1K 5% 1/4W F
(DE975)
R255 1-249-417-11 CARBON 1K 5% 1/4W F
(DE975)
R256 1-249-417-11 CARBON 1K 5% 1/4W F
(DE975)
R257 1-249-424-11 CARBON 3.9K 5% 1/4W F
(DE975)
R258 1-249-437-11 CARBON 47K 5% 1/4W
(DE975)
R259 1-249-437-11 CARBON 47K 5% 1/4W
(DE975)
R260 1-249-437-11 CARBON 47K 5% 1/4W
(DE975)
R261 1-249-418-11 CARBON 1.2K 5% 1/4W F
(DE975)
R262 1-249-437-11 CARBON 47K 5% 1/4W
(DE975)
R263 1-249-393-11 CARBON 10 5% 1/4W F
(DE975)
R264 1-249-393-11 CARBON 10 5% 1/4W F
(DE975)
R271 1-247-804-11 CARBON 75 5% 1/4W
R272 1-247-804-11 CARBON 75 5% 1/4W
R273 1-247-804-11 CARBON 75 5% 1/4W
R274 1-247-804-11 CARBON 75 5% 1/4W
R275 1-247-804-11 CARBON 75 5% 1/4W
R276 1-247-804-11 CARBON 75 5% 1/4W
R277 1-247-804-11 CARBON 75 5% 1/4W
R278 1-247-804-11 CARBON 75 5% 1/4W
< VIBRATOR >
X251 1-781-821-21 VIBRATOR, CRYSTAL (14.31818MHz)(DE975)
************************************************************
VIDEO
