Sony STR-DE875 - Video 3 Board and Miscellaneous Parts

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
56
STR-DE875/DE975
1-680-592-11 VIDEO 3 BOARD (DE975)
*************
< CAPACITOR >
C152 1-128-805-11 CERAMIC 47PF 5% 50V
(DE975)
C153 1-128-809-11 CERAMIC 100PF 5% 50V
(DE975)
C154 1-128-809-11 CERAMIC 100PF 5% 50V
(DE975)
C155 1-128-821-11 CERAMIC 1000PF 5% 50V
(DE975)
C156 1-128-821-11 CERAMIC 1000PF 5% 50V
(DE975)
< CONNECTOR >
CNP104 1-784-922-11 PIN, CONNECTOR 5P (DE975)
< JACK >
J140 1-815-431-11 JACK, PIN 3P (VIDE3 INPUT AUDIO R/L,VIDEO)
(DE975)
< RESISTOR >
R151 1-249-417-11 CARBON 1K 5% 1/4W F
(DE975)
R152 1-249-417-11 CARBON 1K 5% 1/4W F
(DE975)
************************************************************
MISCELLANEOUS
**************
57 1-769-907-11 WIRE (FLAT TYPE) (9 CORE) (DE875)
57 1-773-041-11 WIRE (FLAT TYPE) (17 CORE) (DE975)
59 1-693-539-21 TUNER UNIT (DE875:US,CND/DE975)
59 1-693-540-21 TUNER UNIT (DE875:AEP,UK,E,MY,SP,CH,AUS)
60 1-773-004-11 WIRE (FLAT TYPE) (15 CORE) (DE975)
61 1-773-002-11 WIRE (FLAT TYPE) (15 CORE)
61 1-773-007-11 WIRE (FLAT TYPE) (15 CORE) (DE875)
0 68 1-696-847-11 CORD, POWER (DE875:AUS)
0 68 1-777-071-21 CORD, POWER (DE875:AEP,UK,E,MY,SP)
0 68 1-783-205-11 CORD, POWER (DE875:CH)
0 68 1-783-820-11 CORD, POWER (DE875:CND,US/DE975)
0 71 1-569-008-21 ADAPTOR, CONVERSION 2P (DE875:E)
0 T901 1-435-944-11 POWER TRANSFORMER (DE875:E)
0 T901 1-435-942-11 TRANSFORMER, POWER
(DE875:AEP,UK,MY,SP,CH)
0 T901 1-435-943-11 TRANSFORMER, POWER (DE875:AUS)
0 T901 1-435-945-11 TRANSFORMER, POWER
(DE875:US/DE975:US)
0 T901 1-435-946-11 TRANSFORMER, POWER
(DE875:CND/DE975:CND)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
ACCESSORIES & PACKING MATERIALS
*******************************
1-476-552-21 COMMANDER, STANDARD (RM-U305A)
(DE875:AEP,UK)
1-476-606-11 REMOTE COMMANDER (RM-PP505)
(DE875:US,CND,E,MY,SP,CH,AUS)
1-476-607-11 REMOTE COMMANDER (RM-PP505L) (DE975)
1-501-374-11 ANTENNA, LOOP (AM)
1-501-594-11 ANTENNA (FM) (DE875:AEP,UK,CH,MY,SP,AUS)
1-793-184-21 CONNECTOR (F TYPE ADAPTOR) (FM)
(DE875:US,CND,E/DE975)
4-228-696-01 COVER, BATTERY (FOR RM-U305A)
(DE875:AEP,UK)
4-983-536-01 COVER, BATTERY
(FOR RM-PP505, RM-PP505L) (EXCEPT DE875:AEP,UK)
4-234-334-11 INSTRUCTION MANUAL (ENGLISH)
(DE875:US/DE975:US)
4-234-334-21 INSTRUCTION MANUAL (FRENCH)
(DE875:CND/DE975:CND)
4-234-334-31 INSTRUCTION MANUAL (ENGLISH)
(DE875:E,MY,SP,CH,AUS)
4-234-334-41 INSTRUCTION MANUAL
(FRENCH,SPANISH,CHINESE)(DE875:E,MY,SP)
4-234-334-51 INSTRUCTION MANUAL (CHINESE)(DE875:CH)
4-234-334-61 INSTRUCTION MANUAL (ENGLISH)
(DE875:AEP,UK)
4-234-334-71 INSTRUCTION MANUAL
(CHINESE, DUTCH, SWEDISH)(DE875:AEP)
4-234-334-81 INSTRUCTION MANUAL (GERMAN, SPANISH)
(DE875:AEP)
4-234-334-91 INSTRUCTION MANUAL (ITALIAN, POLISH)
(DE875:AEP)
4-235-738-11 INSTRUCTION MANUAL (DENISH,FINNISH)
(DE875:AEP)
4-236-897-11 INSTRUCTION MANUAL (ENGLISH)
VIDEO 3
