— 62 —
Pin No.
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
Description
L: HiFi, H: ES.
Control-A1.
Control-A1.
Ground.
Encoder input (Function-B).
Encoder input (Function-A).
Not used.
Not used.
Not used.
Not used.
Ground.
Reset.
Ground.
Ceramic oscillator, 4 MHz.
Ceramic oscillator, 4 MHz.
5V (Backup power supply).
LED output (TUNER).
LED output (PHONO).
LED output (MUTE).
LED output (IR-LEARN).
LED output (DIRECT PASS).
LED output (DISCRETE).
LED output (VOLUME).
LED output (BASS BOOST).
SPEAKER A signal input.
SPEAKER B signal input.
POWER key input.
LED output (TV) for video.
LED output (LD) for video.
M-BUS (VIDEO 1) input.
I/O
—
I
O
—
I
I
—
—
—
—
—
I
—
O
I
—
O
O
O
O
O
O
O
O
I
I
I
O
O
I
Label Name
GND
AUBUS IN
AUBUS OUT
GND
EN-FNC.B
EN-FNC.A
UP/DOWN-B
UP/DOWN-A
LEFT/RIGHT-B
LEFT/RIGHT-A
GND
RESET
Vss
X0
X1
Vcc
LED- TUNER
LED-PHONO
LED-MUTE
LED-LEARN
LED-DIRECT
LED-INPUT
LED-VOL
LED-BASSB
SP-A
SP-B
PW-SW
LED-TV (V)
LED-LD (V)
MBUS-V1
