Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 75 —
SECTION 4
ELECTRICAL PARTS LIST
Note:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
CND : Canadian AUS: Australian
CH : Chinese G : German
AED : North European EE : East European
MY : Malaysia SP : Singapore
When indicating parts by reference number,
please include the board naame.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
* A-4398-230-A AMP BOARD, COMPLETE (DE915:US,CND,PX)
********************
* A-4398-280-A AMP BOARD, COMPLETE (V909/VE910:E,SP,
********************* MY)
* A-4398-286-A AMP BOARD, COMPLETE (VE910:AEP,UK,G,
********************* AED,EE)
* A-4398-288-A AMP BOARD, COMPLETE (DE915:AUS)
********************
* 1-537-738-21 TERMINAL, EARTH
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C520 1-126-967-11 ELECT 47uF 20% 16V
C521 1-107-597-11 CERAMIC 22PF 10% 500V
C522 1-107-597-11 CERAMIC 22PF 10% 500V
C523 1-162-286-31 CERAMIC 220PF 10% 50V
C524 1-126-964-11 ELECT 10uF 20% 50V
C525 1-136-157-00 FILM 0.022uF 5% 50V
C526 1-136-153-00 FILM 0.01uF 5% 50V
C570 1-126-967-11 ELECT 47uF 20% 16V
C571 1-107-597-11 CERAMIC 22PF 10% 500V
C572 1-107-597-11 CERAMIC 22PF 10% 500V
C573 1-162-286-31 CERAMIC 220PF 10% 50V
C574 1-126-964-11 ELECT 10uF 20% 50V
C575 1-136-157-00 FILM 0.022uF 5% 50V
C576 1-136-153-00 FILM 0.01uF 5% 50V
C590 1-126-935-11 ELECT 470uF 20% 6.3V
C598 1-126-965-11 ELECT 22uF 20% 50V
C620 1-126-967-11 ELECT 47uF 20% 16V
C621 1-107-597-11 CERAMIC 22PF 10% 500V
C622 1-107-597-11 CERAMIC 22PF 10% 500V
C623 1-162-286-31 CERAMIC 220PF 10% 50V
C803 1-117-950-11 ELECT(SOLID) 10000uF 20% 63V
(V909/VE910)
C803 1-109-932-11 ELECT 10000uF 20% 71V
(DE915)
C804 1-117-950-11 ELECT(SOLID) 10000uF 20% 63V
(V909/VE910)
C804 1-109-932-11 ELECT 10000uF 20% 71V
(DE915)
C807 1-126-967-11 ELECT 47uF 20% 16V
C808 1-126-967-11 ELECT 47uF 20% 16V
C810 1-126-967-11 ELECT 47uF 20% 16V
C811 1-126-952-11 ELECT 1000uF 20% 35V
C812 1-126-951-11 ELECT 470uF 20% 35V
C817 1-126-967-11 ELECT 47uF 20% 50V
C818 1-126-967-11 ELECT 47uF 20% 50V
< CONNECTOR >
CNP701 1-564-320-00 PIN, CONNECTOR (B2P-VH) 2P
CNP702 1-695-091-11 PIN, CONNECTOR (PC BOARD) 15P
CNS502 1-770-404-11 HOUSING,CONNECTOR(PC BOARD)11P
CNS602 1-770-404-11 HOUSING,CONNECTOR(PC BOARD)11P
CNS701 1-569-323-11 SOCKET, CONNECTOR 19P
< DIODE >
D501 8-719-987-63 DIODE 1N4148M
D502 8-719-010-06 DIODE UZ-2.2BS
D503 8-719-010-06 DIODE UZ-2.2BS
D504 8-719-987-63 DIODE 1N4148M
D505 8-719-987-63 DIODE 1N4148M
D506 8-719-987-63 DIODE 1N4148M
D507 8-719-987-63 DIODE 1N4148M
D508 8-719-987-63 DIODE 1N4148M
D512 8-719-987-63 DIODE 1N4148M
D545 8-719-987-63 DIODE 1N4148M
D546 8-719-987-63 DIODE 1N4148M
D547 8-719-987-63 DIODE 1N4148M
D548 8-719-815-85 DIODE 1S1585
D549 8-719-815-85 DIODE 1S1585
D551 8-719-987-63 DIODE 1N4148M
D552 8-719-010-06 DIODE UZ-2.2BS
D553 8-719-010-06 DIODE UZ-2.2BS
D554 8-719-987-63 DIODE 1N4148M
D555 8-719-987-63 DIODE 1N4148M
D556 8-719-987-63 DIODE 1N4148M
D601 8-719-987-63 DIODE 1N4148M
D602 8-719-010-06 DIODE UZ-2.2BS
D603 8-719-010-06 DIODE UZ-2.2BS
D604 8-719-987-63 DIODE 1N4148M
D608 8-719-987-63 DIODE 1N4148M
D611 8-719-987-63 DIODE 1N4148M
D647 8-719-987-63 DIODE 1N4148M (DE915)
D648 8-719-987-63 DIODE 1N4148M (DE915)
D651 8-719-987-63 DIODE 1N4148M
D711 8-719-987-63 DIODE 1N4148M
D716 8-719-987-63 DIODE 1N4148M
D807 8-719-002-73 DIODE UZL-36M
< IC >
IC801 8-759-391-87 IC BA78M12P
IC803 8-759-604-45 IC M5F79M12
AMP
