Sony STR-DE915 - Page 36

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 76 —
< COIL >
L501 1-411-906-11 COIL, AIR-CORE (V909/VE910)
L501 1-420-872-00 COIL, AIR-CORE (DE915)
L551 1-411-906-11 COIL, AIR-CORE (V909/VE910)
L551 1-420-872-00 COIL, AIR-CORE (DE915)
< TRANSISTOR >
Q504 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q505 8-729-209-15 TRANSISTOR 2SD2012
Q506 8-749-010-25 IC MN2488-OPY-M
Q507 8-749-010-26 IC MP1620-OPY-M
Q508 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q509 8-729-281-53 TRANSISTOR 2SC1815-GR
Q510 8-729-900-63 TRANSISTOR DTA124ES
Q511 8-729-900-63 TRANSISTOR DTA124ES
Q546 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q547 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q548 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q549 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q554 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q555 8-729-209-15 TRANSISTOR 2SD2012
Q556 8-749-010-25 IC MN2488-OPY-M
Q557 8-749-010-26 IC MP1620-OPY-M
Q558 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q559 8-729-281-53 TRANSISTOR 2SC1815-GR
Q560 8-729-900-63 TRANSISTOR DTA124ES
Q561 8-729-900-63 TRANSISTOR DTA124ES
Q596 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q604 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q605 8-729-209-15 TRANSISTOR 2SD2012
Q606 8-749-010-25 IC MN2488-OPY-M
Q607 8-749-010-26 IC MP1620-OPY-M
Q608 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q610 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q612 8-729-281-53 TRANSISTOR 2SC1815-GR (DE915)
Q613 8-729-281-53 TRANSISTOR 2SC1815-GR
Q614 8-729-201-53 TRANSISTOR 2SA1015-GR (DE915)
Q615 8-729-900-36 TRANSISTOR DTC124ES (DE915)
Q616 8-729-900-36 TRANSISTOR DTC124ES
Q617 8-729-900-36 TRANSISTOR DTC124ES (DE915)
Q618 8-729-900-63 TRANSISTOR DTA124ES (DE915)
Q801 8-729-209-15 TRANSISTOR 2SD2012
< RESISTOR >
R521 1-249-437-11 CARBON 47K 5% 1/4W
(DE915)
R522 1-247-840-00 CARBON 2.4K 5% 1/4W
(V909/VE910)
R522 1-249-421-11 CARBON 2.2K 5% 1/4W F
(DE915)
R523 1-249-414-11 CARBON 560 5% 1/4W F
! R524 1-249-408-11 CARBON 180 5% 1/4W F
! R525 1-249-408-11 CARBON 180 5% 1/4W F
! R526 1-233-352-41 ENCAPSULATED COMPONENT
R527 1-247-850-11 CARBON 6.2K 5% 1/4W
R528 1-249-419-11 CARBON 1.5K 5% 1/4W F
R529 1-247-866-11 CARBON 30K 5% 1/4W
R530 1-249-421-11 CARBON 2.2K 5% 1/4W F
R531 1-249-433-11 CARBON 22K 5% 1/4W
R532 1-249-437-11 CARBON 47K 5% 1/4W
! R533 1-249-393-11 CARBON 10 5% 1/4W F
! R534 1-249-389-11 CARBON 4.7 5% 1/4W F
R535 1-249-431-11 CARBON 15K 5% 1/4W
R536 1-249-439-11 CARBON 68K 5% 1/4W
(V909/VE910)
R536 1-249-441-11 CARBON 100K 5% 1/4W
(DE915)
R539 1-249-427-11 CARBON 6.8K 5% 1/4W F
R540 1-249-417-11 CARBON 1K 5% 1/4W F
R541 1-249-429-11 CARBON 10K 5% 1/4W
R547 1-249-425-11 CARBON 4.7K 5% 1/4W F
R548 1-249-429-11 CARBON 10K 5% 1/4W
! R549 1-249-393-11 CARBON 10 5% 1/4W F
R550 1-249-429-11 CARBON 10K 5% 1/4W
R571 1-249-437-11 CARBON 47K 5% 1/4W
(DE915)
R572 1-247-840-00 CARBON 2.4K 5% 1/4W
(V909/VE910)
R572 1-249-421-11 CARBON 2.2K 5% 1/4W F
(DE915)
R573 1-249-414-11 CARBON 560 5% 1/4W F
! R574 1-249-408-11 CARBON 180 5% 1/4W F
! R575 1-249-408-11 CARBON 180 5% 1/4W F
! R576 1-233-352-41 ENCAPSULATED COMPONENT 0.22X2 2W
R577 1-247-850-11 CARBON 6.2K 5% 1/4W
R578 1-249-419-11 CARBON 1.5K 5% 1/4W F
R579 1-247-866-11 CARBON 30K 5% 1/4W
R580 1-249-421-11 CARBON 2.2K 5% 1/4W F
R581 1-249-433-11 CARBON 22K 5% 1/4W
R582 1-249-437-11 CARBON 47K 5% 1/4W
! R583 1-249-393-11 CARBON 10 5% 1/4W F
! R584 1-249-389-11 CARBON 4.7 5% 1/4W F
R585 1-249-431-11 CARBON 15K 5% 1/4W
R586 1-249-429-11 CARBON 10K 5% 1/4W
R587 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R588 1-249-393-11 CARBON 10 5% 1/4W F
R621 1-249-437-11 CARBON 47K 5% 1/4W
(DE915)
R622 1-247-840-00 CARBON 2.4K 5% 1/4W
(V909/VE910)
R622 1-249-421-11 CARBON 2.2K 5% 1/4W F
(DE915)
R623 1-249-414-11 CARBON 560 5% 1/4W F
! R624 1-249-408-11 CARBON 180 5% 1/4W F
! R625 1-249-408-11 CARBON 180 5% 1/4W F
! R626 1-233-352-41 ENCAPSULATED COMPONENT 0.22X2 2W
R627 1-247-850-11 CARBON 6.2K 5% 1/4W
R628 1-249-419-11 CARBON 1.5K 5% 1/4W F
R632 1-249-437-11 CARBON 47K 5% 1/4W
R640 1-216-450-00 METAL OXIDE 82 5% 2W F
(DE915)
R641 1-249-441-11 CARBON 100K 5% 1/4W
(DE915)
R642 1-216-454-11 METAL OXIDE 390 5% 2W F
(V909/VE910)
R642 1-215-889-00 METAL OXIDE 330 5% 2W F
(DE915)
R643 1-249-441-11 CARBON 100K 5% 1/4W
R644 1-215-890-11 METAL OXIDE 470 5% 2W F
(DE915)
AMP
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
