Sony STR-DE915 - Electrical Parts List - Board Components; Components for AMP, AMP JOINT, AUDIO, BALANCE Boards

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 77 —
R645 1-249-441-11 CARBON 100K 5% 1/4W
(DE915)
R650 1-249-425-11 CARBON 4.7K 5% 1/4W F
R651 1-249-429-11 CARBON 10K 5% 1/4W
! R652 1-249-393-11 CARBON 10 5% 1/4W F
R739 1-215-868-00 METAL OXIDE 680 5% 1W F
R789 1-215-868-00 METAL OXIDE 680 5% 1W F
! R802 1-249-381-11 CARBON 1 5% 1/4W F
R803 1-247-843-11 CARBON 3.3K 5% 1/4W
< RELAY >
RY501 1-515-920-11 RELAY (24V)
RY502 1-515-920-11 RELAY (24V)
RY602 1-515-793-11 RELAY
< TERMINAL >
* TM501 1-537-699-11 TERMINAL BOARD (SP) (FRONT SPEAKERS)
************************************************************
* 1-665-791-11 AMP JOINT (F) BOARD
*******************
< CONNECTOR >
CNP501 1-770-553-11 CONNECTOR, BOARD TO BOARD 11P
CNP502 1-770-553-11 CONNECTOR, BOARD TO BOARD 11P
************************************************************
* 1-665-792-11 AMP JOINT (B) BOARD
*******************
< CONNECTOR >
CNP601 1-770-553-11 CONNECTOR, BOARD TO BOARD 11P
CNP602 1-770-553-11 CONNECTOR, BOARD TO BOARD 11P
************************************************************
* 1-665-786-11 AUDIO (2F) BOARD
**************
< CAPACITOR >
C398 1-162-282-31 CERAMIC 100PF 10% 50V
C399 1-162-294-31 CERAMIC 0.001uF 10% 50V
CC08 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC09 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC10 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC11 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC12 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC13 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC58 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC59 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC60 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC61 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC62 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC63 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
< CONNECTOR >
CNS302 1-695-093-11 SOCKET, CONNECTOR 9P
< IC >
IC303 8-759-805-14 IC LC7822
< JACK >
J304 1-766-394-11 JACK, PIN 6P (VIDEO 1 IN OUT,VIDEO 2 IN)
J305 1-766-394-11 JACK, PIN 6P (VIDEO 2 OUT,LD/DVD,TV/DBS)
< RESISTOR >
R318 1-249-417-11 CARBON 1K 5% 1/4W F
R319 1-249-417-11 CARBON 1K 5% 1/4W F
R320 1-249-417-11 CARBON 1K 5% 1/4W F
R321 1-249-417-11 CARBON 1K 5% 1/4W F
R322 1-249-417-11 CARBON 1K 5% 1/4W F
R323 1-249-417-11 CARBON 1K 5% 1/4W F
R368 1-249-417-11 CARBON 1K 5% 1/4W F
R369 1-249-417-11 CARBON 1K 5% 1/4W F
R370 1-249-417-11 CARBON 1K 5% 1/4W F
R371 1-249-417-11 CARBON 1K 5% 1/4W F
R372 1-249-417-11 CARBON 1K 5% 1/4W F
R373 1-249-417-11 CARBON 1K 5% 1/4W F
R398 1-249-417-11 CARBON 1K 5% 1/4W F
R399 1-249-425-11 CARBON 4.7K 5% 1/4W F
************************************************************
* 1-665-815-11 BALANCE BOARD
*************
< VARIABLE RESISTOR >
RV402 1-225-447-11 RES, VAR, CARBON 100K/100K (BALANCE)
************************************************************
* A-4398-274-A DIGITAL BOARD, COMPLETE (DE915)
************************
* A-4403-423-A DIGITAL BOARD, COMPLETE (V909/VE910)
************************
< CAPACITOR >
C3101 1-126-964-11 ELECT 10uF 20% 50V
C3102 1-126-964-11 ELECT 10uF 20% 50V
C3103 1-130-467-00 MYLAR 470PF 5% 50V
C3104 1-130-467-00 MYLAR 470PF 5% 50V
C3105 1-126-964-11 ELECT 10uF 20% 50V
C3106 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C3107 1-106-351-00 MYLAR 2200PF 5% 200V
C3108 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C3110 1-104-665-11 ELECT 100uF 20% 25V
C3111 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C3112 1-126-964-11 ELECT 10uF 20% 50V
C3113 1-126-964-11 ELECT 10uF 20% 50V
C3114 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C3115 1-126-967-11 ELECT 47uF 20% 16V
C3116 1-165-319-11 CERAMIC CHIP 0.1uF 50V
AMP AMP JOINT (F) AMP JOINT (B)
AUDIO (2F) BALANCE DIGITAL
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
