Sony STR-DE915 - Electrical Parts List - S Video Components; S Video Section Components

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 88 —
< CONNECTOR >
CNS214 1-695-092-11 SOCKET, CONNECTOR 7P
< DIODE >
D201 8-719-987-63 DIODE 1N4148M (DE915:US,CND)
D210 8-719-987-63 DIODE 1N4148M (DE915:US,CND)
< IC >
IC201 8-759-135-80 IC uPC358C (DE915:US,CND)
IC203 8-759-061-95 IC SN761200 (EXCEPT DE915:US,CND)
IC204 8-759-061-95 IC SN761200 (EXCEPT DE915:US,CND)
IC223 8-759-388-26 IC NJM2129D (DE915:US,CND)
< JACK >
J201 1-563-330-11 JACK (TV/DBS) (DE915:US,CND)
J202 1-507-967-11 JACK (S-LINK) (DE915:US,CND)
J204 1-537-943-11 TERMINAL, S (MONITOR)
(EXCEPT DE915:US,CND)
J205 1-537-943-11 TERMINAL, S (LD VIDEO IN)
(EXCEPT DE915:US,CND)
J207 1-691-964-11 CONNECTOR (ROUND TYPE) (VIDEO 1 IN)
(EXCEPT DE915:US,CND)
J212 1-563-330-11 JACK (VIDEO 1) (DE915:US,CND)
J213 1-563-330-11 JACK (VIDEO 2) (DE915:US,CND)
J214 1-563-330-11 JACK (MONITOR) (DE915:US,CND)
< COIL >
L203 1-410-521-11 INDUCTOR 100uH
< TRANSISTOR >
Q1 8-729-119-76 TRANSISTOR 2SA1175-HFE
(EXCEPT DE915:US,CND)
Q201 8-729-422-57 TRANSISTOR UN4111
(EXCEPT DE915:US,CND)
Q205 8-729-119-76 TRANSISTOR 2SA1175-HFE
(DE915:US,CND)
Q206 8-729-119-76 TRANSISTOR 2SA1175-HFE
(EXCEPT DE915:US,CND)
Q207 8-729-620-05 TRANSISTOR 2SC2603-EF
(EXCEPT DE915:US,CND)
Q208 8-729-620-05 TRANSISTOR 2SC2603-EF
(EXCEPT DE915:US,CND)
Q209 8-729-620-05 TRANSISTOR 2SC2603TP-EF
(DE915:US,CND)
Q210 8-729-119-76 TRANSISTOR 2SA1175-HFE
(EXCEPT DE915:US,CND)
Q211 8-729-119-76 TRANSISTOR 2SA1175-HFE
(EXCEPT DE915:US,CND)
Q212 8-729-620-05 TRANSISTOR 2SC2603TP-EF
(DE915:US,CND)
Q213 8-729-119-76 TRANSISTOR 2SA1175-HFE
(DE915:US,CND)
Q220 8-729-620-05 TRANSISTOR 2SC2603TP-EF
(DE915:US,CND)
Q222 8-729-119-76 TRANSISTOR 2SA1175-HFE
(DE915:US,CND)
Q223 8-729-620-05 TRANSISTOR 2SC2603TP-EF
(DE915:US,CND)
Q225 8-729-119-76 TRANSISTOR 2SA1175-HFE
(DE915:US,CND)
Q226 8-729-119-76 TRANSISTOR 2SA1175-HFE
(DE915:US,CND)
< RESISTOR >
R1 1-249-413-11 CARBON 470 5% 1/4W F
(DE915:US,CND)
R2 1-249-413-11 CARBON 470 5% 1/4W F
(DE915:US,CND)
R6 1-247-843-11 CARBON 3.3K 5% 1/4W
(DE915:US,CND)
R7 1-249-429-11 CARBON 10K 5% 1/4W
(DE915:US,CND)
R201 1-249-417-11 CARBON 1K 5% 1/4W F
(DE915:US,CND)
R202 1-249-417-11 CARBON 1K 5% 1/4W F
(DE915:US,CND)
R203 1-249-437-11 CARBON 47K 5% 1/4W
(DE915:US,CND)
R205 1-247-807-31 CARBON 100 5% 1/4W
(EXCEPT DE915:US,CND)
R206 1-247-807-31 CARBON 100 5% 1/4W
(EXCEPT DE915:US,CND)
R214 1-249-429-11 CARBON 10K 5% 1/4W
(EXCEPT DE915:US,CND)
R215 1-249-403-11 CARBON 68 5% 1/4W F
(EXCEPT DE915:US,CND)
R218 1-249-403-11 CARBON 68 5% 1/4W F
(EXCEPT DE915:US,CND)
R219 1-249-403-11 CARBON 68 5% 1/4W F
(EXCEPT DE915:US,CND)
R220 1-249-409-11 CARBON 220 5% 1/4W F
(EXCEPT DE915:US,CND)
R221 1-249-414-11 CARBON 560 5% 1/4W F
(DE915:US,CND)
R222 1-249-414-11 CARBON 560 5% 1/4W F
(DE915:US,CND)
R223 1-249-409-11 CARBON 220 5% 1/4W F
(EXCEPT DE915:US,CND)
R224 1-249-433-11 CARBON 22K 5% 1/4W
(DE915:US,CND)
R225 1-249-427-11 CARBON 6.8K 5% 1/4W F
(DE915:US,CND)
R228 1-249-411-11 CARBON 330 5% 1/4W
(EXCEPT DE915:US,CND)
R229 1-249-417-11 CARBON 1K 5% 1/4W F
(DE915:US,CND)
R230 1-249-411-11 CARBON 330 5% 1/4W
(EXCEPT DE915:US,CND)
R233 1-249-426-11 CARBON 5.6K 5% 1/4W
(EXCEPT DE915:US,CND)
R234 1-249-426-11 CARBON 5.6K 5% 1/4W
(EXCEPT DE915:US,CND)
R236 1-249-429-11 CARBON 10K 5% 1/4W
(EXCEPT DE915:US,CND)
R238 1-249-403-11 CARBON 68 5% 1/4W F
(EXCEPT DE915:US,CND)
R239 1-249-403-11 CARBON 68 5% 1/4W F
(EXCEPT DE915:US,CND)
R240 1-249-403-11 CARBON 68 5% 1/4W F
(EXCEPT DE915:US,CND)
R241 1-249-417-11 CARBON 1K 5% 1/4W F
(DE915:US,CND)
R243 1-249-419-11 CARBON 1.5K 5% 1/4W F
(EXCEPT DE915:US,CND)
R244 1-249-419-11 CARBON 1.5K 5% 1/4W F
(EXCEPT DE915:US,CND)
R245 1-249-417-11 CARBON 1K 5% 1/4W F
(DE915:US,CND)
S VIDEO
