• Waveforms
– DIGITAL Board – – HDMI PC Board –
8.A Vp-p
3 Vp-p
1.2 Vp-p
3.4 Vp-p
25 MHz
12.288 MHz
3.086 MHz
12.35 MHz
3.1 Vp-p
12.5 MHz
IC2015 RK (RBCK)
IC2015 RI (RMCK)
IC2015 XL (XOUT)
1 V/DIV, 20 nsec/DIV
1 V/DIV, 50 nsec/DIV
1 V/DIV, 50 nsec/DIV
IC2006 [WD (XTAL)
IC2007 UK (X1)
1 V/DIV, 20 nsec/DIV
1 V/DIV, 50 nsec/DIV
194m Vp-p
27.00 MHz
1 IC3500 4 (XTALOUT)
356m Vp-p
10 MHz
2 IC3000 qa (XOUT)
50m V/DIV, 10 nsec/DIV
100m V/DIV, 50 nsec/DIV
For Schematic Diagrams.
Note:
All capacitors are in μF unless otherwise noted. (p: pF)
50 WV or less are not indicated except for electrolytics
and tantalums.
All resistors are in and
1
/4 W or less unless otherwise
speci ed.
f
: internal component.
2 : non ammable resistor.
5 : usible resistor.
C : panel designation.
THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is printed in each block.)
A : B+ Line.
B : B– Line.
Voltages and waveforms are dc with respect to ground
under no-signal (detuned) conditions.
no mark : TUNER
Voltages are taken with a VOM (Input impedance 10 M).
Voltage variations may be noted due to normal production
tolerances.
Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal production
tolerances.
Circled numbers refer to waveforms.
• Signal path.
L : VIDEO
F : AUDIO
E : TUNER
J : AUDIO (DIGITAL)
c : VIDEO (DIGITAL)
N : MIC
• Abbreviation
AUS : Australian model
EA : Saudi Arabia model
SAF : South African model
For Printed Wiring Boards.
Note:
X : Parts extracted from the component side.
Y : Parts extracted from the conductor side.
f
: Internal component.
: Pattern from the side which enables seeing.
(The other layers' patterns are not indicated.)
Indication of transistor.
C
B
These are omitted.
E
Q
CEB
These are omitted.
Note: The components identi ed by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number speci ed.
Caution:
Pattern face side:
(SIDE B)
Parts face side:
(SIDE A)
Parts on the pattern face side seen from
the pattern face are indicated.
Parts on the parts face side seen from
the parts face are indicated.
Caution:
Pattern face side:
(Conductor Side)
Parts face side:
(Component
Side)
Parts on the pattern face side seen from
the pattern face are indicated.
Parts on the parts face side seen from
the parts face are indicated.
• Abbreviation
AUS : Australian model
EA : Saudi Arabia model
SAF : South African model
