Sony STR-KM7600 - Page 71

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
7171
STR-KM7600
C679 1-136-157-00 FILM 0.022uF 5% 50V
C680 1-126-947-11 ELECT 47uF 20% 35V
C681 1-114-989-81 CERAMIC 47PF 5% 1KV
C682 1-114-989-81 CERAMIC 47PF 5% 1KV
C683 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C684 1-136-157-00 FILM 0.022uF 5% 50V
C685 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C686 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C687 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C688 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C689 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C690 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C691 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C692 1-126-947-11 ELECT 47uF 20% 35V
C693 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C694 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C695 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C697 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C698 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C699 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C700 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C701 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C702 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C703 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
CC500 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
CC501 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
CC504 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
CC505 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
CC506 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
CC507 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
CC508 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
CC521 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
CC522 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
CC523 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
CC524 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
CC525 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
CC526 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
CC527 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
CC528 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
CC529 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
CC530 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
CC531 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
CC532 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
CC533 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
CC534 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
CC536 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
< CONNECTOR >
*
CN553 1-564-506-11 PLUG, CONNECTOR 3P
CN554 1-564-242-00 PIN, CONNECTOR (3.96mm PITCH) 5P
CN555 1-770-385-11 CONNECTOR, BOARD TO BOARD 18P
CN556 1-770-385-11 CONNECTOR, BOARD TO BOARD 18P
*
CN558 1-564-509-11 PLUG, CONNECTOR 6P
< COMPOSITION CIRCUIT BLOCK >
CP600 1-234-182-11 ENCAPSULATED COMPONENT
CP601 1-234-182-11 ENCAPSULATED COMPONENT
CP602 1-234-182-11 ENCAPSULATED COMPONENT
CP603 1-234-182-11 ENCAPSULATED COMPONENT
CP604 1-234-182-11 ENCAPSULATED COMPONENT
CP605 1-234-182-11 ENCAPSULATED COMPONENT
CP606 1-234-182-11 ENCAPSULATED COMPONENT
< DIODE >
D401 8-719-053-18 DIODE 1SR154-400TE-25
D402 8-719-053-18 DIODE 1SR154-400TE-25
D403 8-719-053-18 DIODE 1SR154-400TE-25
D404 8-719-053-18 DIODE 1SR154-400TE-25
D406 6-501-817-01 DIODE MA2J1110GLS0
D407 8-719-061-07 DIODE D5SBA60-F
D412 8-719-053-18 DIODE 1SR154-400TE-25
D421 6-501-817-01 DIODE MA2J1110GLS0
D422 6-501-817-01 DIODE MA2J1110GLS0
D423 6-501-817-01 DIODE MA2J1110GLS0
D425 6-501-817-01 DIODE MA2J1110GLS0
D441 6-501-817-01 DIODE MA2J1110GLS0
D451 6-501-817-01 DIODE MA2J1110GLS0
D571 6-501-712-01 DIODE MAZ8030G0LS0
D581 6-500-335-01 DIODE MC2838-T112-1
D582 6-500-335-01 DIODE MC2838-T112-1
D600 6-501-817-01 DIODE MA2J1110GLS0
D601 6-501-817-01 DIODE MA2J1110GLS0
D602 6-501-817-01 DIODE MA2J1110GLS0
D603 6-501-817-01 DIODE MA2J1110GLS0
D604 6-501-817-01 DIODE MA2J1110GLS0
D605 6-501-817-01 DIODE MA2J1110GLS0
D606 6-501-817-01 DIODE MA2J1110GLS0
D607 6-501-817-01 DIODE MA2J1110GLS0
D608 6-501-817-01 DIODE MA2J1110GLS0
D609 6-501-817-01 DIODE MA2J1110GLS0
D610 6-501-817-01 DIODE MA2J1110GLS0
D611 6-501-817-01 DIODE MA2J1110GLS0
D612 6-501-817-01 DIODE MA2J1110GLS0
D613 6-501-817-01 DIODE MA2J1110GLS0
D614 6-501-734-01 DIODE MAZ8056GMLS0
D615 6-501-817-01 DIODE MA2J1110GLS0
D616 6-501-817-01 DIODE MA2J1110GLS0
D617 6-501-817-01 DIODE MA2J1110GLS0
< FUSE >
0
F401 1-523-084-11 FUSE 2A 250V
0
F402 1-523-084-11 FUSE 2A 250V
< HOLDER, FUSE >
FH001 1-533-217-41 HOLDER, FUSE
FH002 1-533-217-41 HOLDER, FUSE
FH003 1-533-217-41 HOLDER, FUSE
FH004 1-533-217-41 HOLDER, FUSE
< IC >
IC412 6-712-294-01 IC KIA7807API-U/PF
IC413 6-712-295-01 IC KIA7907PI
IC551 6-716-394-01 IC BD3470KS2
IC600 6-710-828-01 IC STK350-530T-E
IC601 6-710-828-01 IC STK350-530T-E
IC602 6-710-828-01 IC STK350-530T-E
IC603 6-710-828-01 IC STK350-530T-E
< JACK >
J521 1-774-411-11 JACK, PIN 6P (SA-CD/CD/CD-R IN/OUT, TV IN)
MAIN
