Input sources which can be output to Zone 2 (analog connection)
The following input sources can be output to Zone 2.
Only 2ch PCM signals are output to Zone 2.
Digital audio stream signals such as DSD and Dolby Digital are not output to Zone 2.
Multi-channel stream signals are automatically converted to 2 channels signals, and then
output to Zone 2 if the same source signals as the main zone are selected in Zone 2.
Note
When [FM TUNER] or [AM TUNER] is selected at the same time in the main zone and Zone 2 or
Zone 3, the item most recently selected will be set.
If you change the sound field or speaker settings in the main zone while the input for Zone 2 is set to
[SOURCE] or the same input is selected in the main zone and Zone 2, the sound may also be
momentarily interrupted in Zone 2.
Input sources which can be output to Zone 2 (HDMI connection)
The following input sources can be output to Zone 2 when Zone 2 speakers are connected to
another receiver or amplifier connected to the HDMI OUT B (ZONE 2) jack.
Input name Input source
SOURCE
Signals from the current input in main zone
BD/DVD
Source signal from the HDMI IN 1 (BD/DVD) jack (*1)
Source signal from the DIGITAL COAXIAL IN (BD/DVD) jack (*1)
SAT/CATV
Source signal from the HDMI IN 2 (SAT/CATV) jack (*1)
GAME
Source signal from the HDMI IN 6 (GAME) jack on the front panel (*1)
STB
Source signal from the HDMI IN 3 (STB) jack
VIDEO
Source signal from the HDMI IN 4 (VIDEO) jack (*1)
Source signal from the VIDEO IN VIDEO jack
Source signal from the AUDIO IN VIDEO jacks
AUX
Source signal from the VIDEO IN AUX jack
Source signal from the DIGITAL OPTICAL IN 1 (AUX) jack (*1)
Source signal from the AUDIO IN AUX jacks
TV
TV sound from the DIGITAL OPTICAL IN 2 (TV) jack (*1)
Source signal from the AUDIO IN TV jacks
SA-CD/CD
Source signal from the HDMI IN 5 (SA-CD/CD) jack (*1)
Source signal from the AUDIO IN SA-CD/CD jacks
FM TUNER
FM broadcast received through the built-in tuner
AM TUNER
AM broadcast received through the built-in tuner
The following restrictions are set on the digital audio signals input from the HDMI, coaxial and optical input jacks
on the receiver:
*1
If the digital audio signals input from the HDMI, coaxial and optical input jacks on the receiver are not output to
Zone 2, set the audio output to 2ch PCM on the connected device. For details, refer to the operating instructions
of the connected device.
Input name Input source
SOURCE
Signals from the current input in main zone
BD/DVD
Source signal from the HDMI IN 1 (BD/DVD) jack
Source signal from the COMPONENT VIDEO IN 1 (BD/DVD) jacks (*2)
Source signal from the DIGITAL COAXIAL IN (BD/DVD) jack (*3)
SAT/CATV
Source signal from the HDMI IN 2 (SAT/CATV) jack
GAME
Source signal from the HDMI IN 6 (GAME) jack on the front panel
STB
Source signal from the HDMI IN 3 (STB) jack
VIDEO
Source signal from the HDMI IN 4 (VIDEO) jack
Source signal from the COMPONENT VIDEO IN 2 (VIDEO) jacks (*2)
Source signal from the VIDEO IN VIDEO jack (*2)
Source signal from the AUDIO IN VIDEO jacks
Source signal from the VIDEO IN AUX jack (*2)
