104
Specifications
Appendixes
Appendixes
Specifications
Picture performance
Panel OLED panel
Picture size (diagonal)
623.4 mm (24
5
/
8
inches)
Effective picture size (H × V)
543.4 × 305.6 mm
(21
1
/
2
× 12
1
/
8
inches)
Resolution (H × V)
1920 × 1080 pixels (Full HD)
Aspect 16:9
Pixel efficiency 99.99%
Panel drive RGB 10-bit
Panel frame rate 48 Hz, 50 Hz, 60 Hz, 72 Hz, 75 Hz
1)
See “Picture Frame Display” (page 123).
1) 48 Hz, 60 Hz and 72 Hz are also compatible with a
frame rate of 1/1.001.
Viewing angle (Panel specification)
89º/89º/89º/89º (typical)
(up/down/left/right, contrast > 10:1)
Normal scan 0% scan
Native scan Mapping the pixels of the signal to the
panel to one-to-one mode, or
displaying an SD signal of non-
square pixels (the number of H
pixels of the signal system is 720 or
1440) or a 640 × 480 SD signal of
HDMI/DisplayPort video by scaling
processing of doubling for the V
direction and correct aspect ratio for
the H direction and also optimizing
and displaying a picture by
modifying the aperture coefficient
value, filter coefficient value, etc.
Under scan 3% under scan
Over scan Mask of 5% over scan portion in the
normal scan
Color temperature
D55, D61, D65, D93, D-Cine
2)
, (Setting
possible in other color temperature)
2) D-Cine: x=0.314 y=0.351
Standard luminance
100 cd/m
2
(Preset1 to Preset5)
48 cd/m
2
(Preset (D-Cine))
(100% white signal input)
Color space (color gamut)
ITU-R BT.709, EBU, SMPTE-C,
D-Cine
3)
, E250 Native
4)
,
S-GAMUT
5)
3) Chromaticity point of SMPTE RP 431-2 is not
covered in full.
4) The BVM-E250 individual chromaticity points.
The widest color space setting of the signal
reproduced by the BVM-E250
(Typical)
5) For displaying the color gamut of the wide color
space mode S-GAMUT, which is available for the
F23 or F35 Digital Cinematography Camera
Warm-up time Approx. 30 minutes
Input
SDI BNC (×2)
Input impedance: 75 ohms unbalanced
Signal format
See “Available Signal Systems”
(page 109) and “Available Signal
Formats” (page 111).
Sampling frequency
3G-SDI:
Y/Cb/Cr (4:2:2)
148.5MHz/74.25MHz/74.25MHz
Y/Cb/Cr (4:4:4)
148.5MHz/148.5MHz/148.5MHz
G/B/R (4:4:4)
148.5MHz/148.5MHz/148.5MHz
HD-SDI:
Y/Cb/Cr (4:2:2)
74.25MHz/37.125MHz/37.125MHz
SD-SDI:
Y/Cb/Cr (4:2:2)
13.5MHz/6.75MHz/6.75MHz
xy
R 0.681 0.319
G 0.189 0.724
B 0.141 0.051
