Aperture Modification Frequency
Appendixes
Aperture Modification Frequency
Signal system
Serial digital input Analog input HDMI/DisplayPort input
SD-SDI 3G/HD-SDI
Composite
(Y/C)
Component (YPbPr)
RGB
Component (YCbCr)
RGB
Standard SDI input/Input adaptor
576/50i 5 MHz 5 MHz 5 MHz
487/59.94i 5 MHz 5 MHz 5 MHz
1080/24
1)
PsF
25 MHz 25 MHz
1080/24
1)
P
25 MHz 25 MHz
1080/50i (25PsF) 25 MHz 25 MHz
1080/25P 25 MHz 25 MHz
1080/60
1)
i (30
1)
PsF)
25 MHz 25 MHz
1080/30
1)
P
25 MHz 25 MHz
720/24
1)
P
25 MHz
720/25P 25 MHz
720/30
1)
P
25 MHz
720/50P 25 MHz 25 MHz
720/60
1)
P
25 MHz 25 MHz
2048×1080/24
1)
PsF
25 MHz
2048×1080/24
1)
P
25 MHz
2048×1080/25PsF 25 MHz
2048×1080/25P 25 MHz
2048×1080/30
1)
PsF
25 MHz
2048×1080/30
1)
P
25 MHz
1080/50P 50 MHz
1080/60
1)
P
50 MHz
HDMI/DisplayPort
640×480/60
1)
P
10 MHz
720×480/60
1)
P
10 MHz
1280×720/60
1)
P
25 MHz
1920×1080/60
1)
i
25 MHz
720 (1440)
2)
×
480/60
1)
i
3)
5 MHz
720×576/50P 10 MHz
1280×720/50P 25 MHz
1920×1080/50i 25 MHz
720 (1440)
2)
×576/50i
3)
5 MHz
1920×1080/60
1)
P
50 MHz
1920×1080/50P 50 MHz
1920×1080/24
1)
P
25 MHz
