Sony Trimaster EL BVM-E250 - Available Signal Systems

109
Available Signal Systems
Appendixes
Available Signal Systems
Standard SDI input/Input adaptor
Signal system
Total lines
per frame
Active lines
per frame
Frame rate
(Hz)
Scanning
format
Aspect
ratio
Standard
Display on the
monitor
720×576/50i 625 576 25 2:1 Interlace 16:9/4:3
Rec.ITU-R
BT.601
575/50I
1440×576/50i
1)
625 576 25 2:1 Interlace 16:9/4:3 575/50I
720×487/59.94i 525 487 30/1.001 2:1 Interlace 16:9/4:3
Rec.ITU-R
BT.601
480/60I
480/59.94I
2)
1440×487/59.94i
1)
525 487 30/1.001 2:1 Interlace 16:9/4:3 480/60I
1920×1080/24PsF 1125 1080 24 Progressive
16:9 SMPTE-274M
1080/24PsF
2.39:1
1920×1080/
23.98PsF
1125 1080 24/1.001 Progressive
16:9 SMPTE-274M
1080/24PsF
1080/23.98PsF
2)
2.39:1
1920×1080/25PsF 1125 1080 25 Progressive
16:9 SMPTE-274M
1080/25PsF
2.39:1
1920×1080/30PsF 1125 1080 30 Progressive
16:9 SMPTE-274M
1080/30PsF
2.39:1
1920×1080/
29.97PsF
1125 1080 30/1.001 Progressive
16:9 SMPTE-274M
1080/30PsF
1080/29.97PsF
2)
2.39:1
1920×1080/24P 1125 1080 24 Progressive
16:9 SMPTE-274M
1080/24P
2.39:1
1920×1080/23.98P 1125 1080 24/1.001 Progressive
16:9 SMPTE-274M
1080/24P
1080/23.98P
2)
2.39:1
1920×1080/25P 1125 1080 25 Progressive
16:9 SMPTE-274M
1080/25P
2.39:1
1920×1080/30P 1125 1080 30 Progressive
16:9 SMPTE-274M
1080/30P
2.39:1
1920×1080/29.97P 1125 1080 30/1.001 Progressive
16:9 SMPTE-274M
1080/30P
1080/29.97P
2)
2.39:1
1920×1080/50i 1125 1080 25 2:1 Interlace
16:9 SMPTE-274M
1080/50I
2.39:1
1920×1080/60i 1125 1080 30 2:1 Interlace
16:9 SMPTE-274M
1080/60I
2.39:1
1920×1080/59.94i 1125 1080 30/1.001 2:1 Interlace
16:9 SMPTE-274M
1080/60I
1080/59.94I
2)
2.39:1
1920×1080/50P 1125 1080 50 Progressive
16:9 SMPTE-274M
1080/50P
2.39:1
1920×1080/60P 1125 1080 60 Progressive
16:9 SMPTE-274M
1080/60P
2.39:1
1920×1080/59.94P 1125 1080 60/1.001 Progressive
16:9 SMPTE-274M
1080/60P
1080/59.94P
2)
2.39:1
1280×720/24P 750 720 24 Progressive 16:9 SMPTE-296M 720/24P
