Sony Trimaster EL BVM-E250 - Page 110

110
Available Signal Systems
Appendixes
1) The analog component signal or analog RGB signal from BKM-229X is processed in 720 dots × 2 (1440 dots).
2) Displayed when a signal is input from the standard SDI input or the BKM-250TG, Format is set to 3G/HD/SD-SDI Auto (page 49) in the Channel
Configuration menu, and the Picture Rate information for the Payload ID superimposed on the input signal is 23.98, 29.97, or 59.94.
• For details on the available signal system for the HDMI/DisplayPort input signal, see “HDMI/DisplayPort” (page 117) of “Available Signal Formats”.
1280×720/23.98P 750 720 24/1.001 Progressive 16:9 SMPTE-296M
720/24P
720/23.98P
2)
1280×720/25P 750 720 25 Progressive 16:9 SMPTE-296M 720/25P
1280×720/30P 750 720 30 Progressive 16:9 SMPTE-296M 720/30P
1280×720/29.97P 750 720 30/1.001 Progressive 16:9 SMPTE-296M
720/30P
720/29.97P
2)
1280×720/50P 750 720 50 Progressive 16:9 SMPTE-296M 720/50P
1280×720/60P 750 720 60 Progressive 16:9 SMPTE-296M 720/60P
1280×720/59.94P 750 720 60/1.001 Progressive 16:9 SMPTE-296M
720/60P
720/59.94P
2)
2048×1080/24PsF 1125 1080 24 Progressive
1.896:1
SMPTE-2048
SMPTE-428
2048 × 1080/
24PsF
2.39:1
2048×1080/
23.98PsF
1125 1080 24/1.001 Progressive
1.896:1
SMPTE-2048
SMPTE-428
2048 × 1080/
24PsF
2048×1080/
23.98PsF
2)
2.39:1
2048×1080/24P 1125 1080 24 Progressive
1.896:1
SMPTE-2048
SMPTE-428
2048 × 1080/
24P
2.39:1
2048×1080/23.98P 1125 1080 24/1.001 Progressive
1.896:1
SMPTE-2048
SMPTE-428
2048×1080/
24P
2048 × 1080/
23.98P
2)
2.39:1
2048×1080/25PsF 1125 1080 25 Progressive
1.896:1
SMPTE-2048
SMPTE-428
2048 × 1080/
25PsF
2.39:1
2048×1080/25P 1125 1080 25 Progressive
1.896:1
SMPTE-2048
SMPTE-428
2048 × 1080/
25P
2.39:1
2048×1080/30PsF 1125 1080 30 Progressive
1.896:1
SMPTE-2048
SMPTE-428
2048 × 1080/
30PsF
2.39:1
2048×1080/
29.97PsF
1125 1080 30/1.001 Progressive
1.896:1
SMPTE-2048
SMPTE-428
2048 × 1080/
30PsF
2048 × 1080/
29.97PsF
2)
2.39:1
2048×1080/30P 1125 1080 30 Progressive
1.896:1
SMPTE-2048
SMPTE-428
2048 × 1080/
30P
2.39:1
2048×1080/29.97P 1125 1080 30/1.001 Progressive
1.896:1
SMPTE-2048
SMPTE-428
2048 × 1080/
30P
2048 × 1080/
29.97P
2)
2.39:1
Signal system
Total lines
per frame
Active lines
per frame
Frame rate
(Hz)
Scanning
format
Aspect
ratio
Standard
Display on the
monitor
