Picture Display Size
Standard SDI input/Input adaptor
1) Also compatible with 1/1.001
2) The analog component signal or analog RGB signal from BKM-229X is processed in 720 dots × 2 (1440 dots).
· Over Scan: The area size where 5% over scan portion in the normal scan is masked.
· Native Scan Aspect Correction: The area over the H size (1920) is not displayed.
Signal system
Aspect
ratio
Native
Scan ×1
Native
Scan ×2
Native Scan
Aspect
Correction
Normal
Scan
Under Scan Over Scan Side by Side
(H) × (V) (H) × (V) (H) × (V) (H) × (V) (H) × (V) (H) × (V) (H) × (V)
720 × 576/50i
4:3
720 × 576 1440 × 1152
1575 × 1152 1477 × 1080 1432 × 1048 1407 × 1029 960 × 702
16:9 2100 × 1152 1920 × 1053 1862 × 1022 1829 × 1003 960 × 527
1440 × 576/50i
2)
4:3
1440 × 1152
1575 × 1152 1477 × 1080 1432 × 1048 1407 × 1029 960 × 702
16:9 2100 × 1152 1920 × 1053 1862 × 1022 1829 × 1003 960 × 527
720 × 487/59.94i
4:3
720 × 487 1440 × 974
1302 × 974 1443 × 1080 1400 × 1048 1374 × 1029 960 × 718
16:9 1736 × 974 1920 × 1077 1862 × 1045 1829 × 1026 960 × 539
1440 × 487/59.94i
2)
4:3
1440 × 974
1302 × 974 1443 × 1080 1400 × 1048 1374 × 1029 960 × 718
16:9 1736 × 974 1920 × 1077 1862 × 1045 1829 × 1026 960 × 539
1920 × 1080/24
1)
PsF
16:9
1920 × 1080
1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
1920 × 1080/25PsF
16:9
1920 × 1080
1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
1920 × 1080/30
1)
PsF
16:9
1920 × 1080
1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
1920 × 1080/24
1)
P
16:9
1920 × 1080
1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
1920 × 1080/25P
16:9
1920 × 1080
1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
1920 × 1080/30
1)
P
16:9
1920 × 1080
1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
1920 × 1080/50i
16:9
1920 × 1080
1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
1920 × 1080/60
1)
i
16:9
1920 × 1080
1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
1920 × 1080/50P
16:9
1920 × 1080
1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
1920 × 1080/60
1)
P
16:9
1920 × 1080
1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
1280 × 720/24
1)
P
16:9
1280 × 720 1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
1280 × 720/25P 16:9
1280 × 720 1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
1280 × 720/30
1)
P
16:9
1280 × 720 1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
1280 × 720/50P 16:9
1280 × 720 1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
1280 × 720/60
1)
P
16:9
1280 × 720 1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
2048 × 1080/24
1)
PsF
1.896:1
2048 × 1080
1920 × 1013 1862 × 982 1829 × 965 960 × 506
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
2048 × 1080/24
1)
P
1.896:1
2048 × 1080
1920 × 1013 1862 × 982 1829 × 965 960 × 506
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
2048 × 1080/25PsF
1.896:1
2048 × 1080
1920 × 1013 1862 × 982 1829 × 965 960 × 506
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
2048 × 1080/25P
1.896:1
2048 × 1080
1920 × 1013 1862 × 982 1829 × 965 960 × 506
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
2048 × 1080/30
1)
PsF
1.896:1
2048 × 1080
1920 × 1013 1862 × 982 1829 × 965 960 × 506
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
2048 × 1080/30
1)
P
1.896:1
2048 × 1080
1920 × 1013 1862 × 982 1829 × 965 960 × 506
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
