Input/Output Connectors and Input Adaptors
Chapter 1 Overview
Input/Output Connectors and Input Adaptors
This monitor is equipped with two 3G/HD/SD-SDI input connectors, an HDMI input connector, and a DisplayPort input
connector for the standard interface.
In this manual, these connectors are referred to as the standard input.
By adding the optional input expansion adaptors, the input/output connector panel can be assembled in a wide variety of
configurations.
The signals that each connector supports are given in the following table. The type of signal to be applied to each input/
output connector is set with the Channel Configuration menu (page 49) .
List of input/output connectors and input adaptors
a: Signal can be reproduced.
a(2): Two adaptors are used.
For details, see “Available Signal Formats” on page 111.
Input signal Standard
input
Input adaptor
BKM-220D BKM-227W BKM-229X BKM-
243HS/
244CC
BKM-
250TG
Serial digital
input
Single-link SD-SDI
Component 525/625
aa aa
Single-link HD-SDI aaa
Dual-link HD-SDI a (2) a
Single-link 3G-SDI aa
Analog input Composite NTSC a
Composite PAL a
Composite PAL-M a
Composite SECAM a
Y/C NTSC a
Y/C PAL a
Y/C PAL-M a
Y/C SECAM a
YPbPr 525i/625i a
RGB 525i/625i a
YPbPr/RGB 1080/24PsF a
YPbPr/RGB 1080/24P a
YPbPr/RGB 1080/50i
(25PsF)
a
YPbPr/RGB 1080/25P a
YPbPr/RGB 1080/60i
(30PsF)
a
YPbPr/RGB 1080/30P a
YPbPr/RGB 720/50P a
YPbPr/RGB 720/60P a
HDMI Video a
Computer a
DisplayPort Video a
Computer a
Number of digital inputs 2 2 – – 2 2
Number of analog inputs – – 1 1 – –
Number of HDMI inputs 1–––––
Number of DisplayPort input 1 – – – – –
