118
Available Signal Formats
Appendixes
1) Also compatible with 1/1.001.
2) RGB/YCbCr format and 6/8/10/12bit are selected automatically according to the input signal.
3) Pixel Repetition = 2 (transmit the same pixel twice)
4) In this manual, the 800 × 600, 1024 × 768, 1280 × 960, 1280 × 1024 and 1400 × 1050 signals are referred to as the HDMI/DisplayPort computer signals.
5) The HDMI signal does not support the RGB/YCbCr 4:4:4 6bit signal.
6) The DisplayPort signal does not support the RGB/YCbCr 4:4:4 12bit signal.
7) The DisplayPort signal does not support this signal system.
• The quantization level of the HDMI/DisplayPort input signal is set in the RGB Range menu (page 55).
• The aspect ratio of the HDMI input signal is manually set when the HDMI Auto menu (page 51) of the Screen Aspect menu is set to Off.
