Channel Configuration Menu
Chapter 3 Menu
RGB Range Sets the quantization range of the 4:4:4 RGB SDI, HDMI or DisplayPort input signal.
HD Sets the quantization range when a 4:4:4 RGB SDI signal is input and the signal system is
1920 × 1080 or 1280 × 720.
Full: 0 (black level) to 1023 (10bit)/4095 (12bit) (white level)
[Limit]: 64(10bit)/256 (12bit) (black level) to 940 (10bit)/3760 (12bit) (white level)
DC 2048 × 1080 Sets the quantization range when a 4:4:4 RGB SDI signal is input and the signal system is
2048 × 1080.
[Full]: 0 (black level) to 1023 (10bit)/4095 (12bit) (white level)
Limit: 64 (10bit)/256 (12bit) (black level) to 940 (10bit)/3760 (12bit) (white level)
HDMI Sets the display mode for the HDMI signal.
Full: 0 (black) to 255 (8bit)/1023 (10bit)/4095 (12bit) (white level)
[Limit]: 16 (8bit)/64 (10bit)/256 (12bit) (black level) to 235 (8bit)/940 (10bit)/3760 (12bit)
(white level)
DisplayPort Sets the display mode for the DisplayPort signal.
[Full]: 0 (black level) to 63 (6bit)/255 (8bit)/1023 (10bit)/4095 (12bit) (white level)
Limit: 4 (6bit)/16 (8bit)/64 (10bit)/256 (12bit) (black level) to 58 (6bit)/235(8bit)/940
(10bit)/3760 (12bit) (white level)
HDMI/DisplayPort Auto Sets the manual or automatic setting for the quantization range of the HDMI or DisplayPort
signal.
Off: Select to use the quantization range set in the HDMI or DisplayPort menu.
[On]: Select to set the quantization range automatically according to the input signal.
1080I/PsF When the 1080i/PsF signal is input, select the display mode.
You can select when Format is set to 3G/HD/SD-SDI Auto, HD/SD-SDI Auto, 4:2:2 YCbCr
10bit, 4:4:4 YCbCr 10bit, 4:4:4 RGB 10bit, 4:4:4 YCbCr 12bit, 4:4:4 RGB 12bit, 4:4:4 XYZ
12bit, Component YPbPr or Component RGB.
When 1080I is selected, the I/P conversion signal is displayed. When 1080PsF is selected,
the progressive conversion (PsF to P) signal is displayed.
When the 1080PsF signal is input and 1080I is selected, the display delay is shortened. The
signal converted from PsF to P is not displayed and the I/P conversion signal is displayed.
When Format is set to 3G/HD/SD-SDI Auto and Payload ID data are superimposed on the
SDI signal, 1080i/PsF processing is performed based on the Payload ID data, regardless of
the setting value.
24PsF Sets the display mode for the 1080/24PsF signal.
You can select from 1080I or [1080PsF].
25PsF/50I Sets the display mode for the 1080/25PsF, 50i signal.
You can select from [1080I] or 1080PsF.
30PsF/60I Sets the display mode for the 1080/30PsF, 60i signal.
You can select from [1080I] or 1080PsF.
Film Cadence Sets the film cadence mode.
The progressive conversion signal is displayed according to the setting.
[Off]: The progressive conversion signal is not displayed in film cadence mode.
2-2: The progressive conversion signal is displayed when the interlace signal of 2-2 pull-
down processing is input
2-3: The progressive conversion signal is displayed when the interlace signal of 2-3 pull-
down processing is input
2-3-3-2: The progressive conversion signal is displayed when the interlace signal of 2-3-
3-2 pull-down processing is input
Notes
• When the 50i interlace signal is input, the mode is automatically set to 2-2, even when 2-3
or 2-3-3-2 is selected.
• The signal is not displayed in film cadence mode when 1080i interlace signal is input and
1080PsF is selected in the 1080I/PsF menu. Set to 1080I.
• As the signal is displayed in film cadence mode by cadence sequence detection based on
the pattern of the input signal, the signal may not be displayed correctly, because of the
pattern of the input signal.
• The signal is not displayed in the film cadence mode when Side by Side, Wipe, Butterfly or
Blending is set to On.
