Sony Trimaster EL BVM-E250 - Page 130

130
Dimensions
Appendixes
When the tilt unit is attached to the BKM-37H
Front
Side
Bottom
When the controller is attached with the
BKM-38H
Front
Side
Bottom
285.7 (11
1
/
4
)
75.7 (3)
483.7 (19
1
/
8
)
266 (10
1
/ 2 )
30 (1
3
/ 16 )
4-M5
6-Ø8
230 (9
1
/
8
)
489.8 (19
3
/ 8 )
30 (1
3
/ 16 )
195 (7
3
/
4
)
30 (1
3
/ 16 )
576 (22
3
/ 4 )
469.6 (19
5
/
8
)
271.6 (10
3
/
4
)
61.6 (2
1
/
2
)
266 (10
1
/ 2 )
30 (1
3
/ 16 )
