2-12. AD BOARD AND B BOARD REMOVAL
1 B board
1 AD board
Main bracket
2-11. H4 BOARD (EXCEPT HW572K90)
AND S BOARD REMOVAL
3 H4 board
2 L screen holder
6 Claws
8 S board
8 S board
7
Sensor
bracket
Sensor
bracket (B)
4 Two screws
(+BVTP 4x12)
1 Four screws
(+BVTP 4x12)
5 Two screws
(+BVTP 4x12)
7 Sensor bracket (A)
6
Two claws
• HW572K90
• Except HW572K90
2-13. F BOARD (EXCEPT HR532N90) AND
G BOARD REMOVAL
5 G board
3 Bracket G
2 Claws
2 Claw
2 Claw
Main bracket
6 F board
4 Four screws
(+BVTP3x12)
1 screw
(+BVTP4x12)
3 Beznet assy
2 Screws,
+BVTP4x16
1 Screws,
tapping, hexagon head
2-10. BEZNET ASSY REMOVAL
