4. SERVICE MODE LIST
3D-COMB uPD64082 ( ) :HW572K90
Reg.No & Name FUNCTION
UHF/VHF & Cvideo Svideo Note: * shows common data.
Standard Non-standard Standard Non-standard
0 NRMD Operation mode setting 0133
1 YAPS Y-output correction 3*
2 CLKS System clock setting 1*
UHF/VHF & Cvideo Svideo
Standard Non-standard Standard Non-standard
3 NSDS Selection for standard/non-standard signal processing 0000
4 MSS Selection for inter-frame/inter-line processing 0*
5 KILS Killer processing selection 1*
UHF/VHF CV/SV
6 CDL C-signal phase with respect to the Y-signal 33
NRMD=0 NRMD=1 NRMD=2 NRMD=3
7 DYCO DY detection coring level (Y motion detection coring) 2222
8 DYGA DY detection gain (Y motion detection gain) 10 10 10 10
9 DCCO DC detection coring level (C motion detection coring) 5555
10 DCGA DC detection gain ( C motion detection gain) 5555
11 YNRL Frame recursive YNR nonlinear filter limit level 1*
12 CNRL Frame recursive CNR nonlinear filter limit level 1*
UHF/VHF Video1-4 Video5&6
13 VTRH Hysteresis for Hsysnc non-standard signal detection 111
14 VTRR Sensitivity for Hsysnc non-standard signal detection 111
15 LDSR Sensitivity for frame non-standard signal detection 222
VM=off VM=Low VM=Mid VM=High
16 VAPG V-aperture compensation gain 0000
17 VAPI V-aperture compensation convergence point 0000
SNNR=0 SNNR=1 SNNR=2 SNNR=3
18 YPET Y peaking filter (BPF) center frequency 30000
19 YPFG Y peaking filter (BPF) gain 9 (8)0123
SNNR=0 SNNR=1 SNNR=2 SNNR=3
20 YHCO Y output high frequency component coring 0111 Note: YHCO & YHCG are defined directly by SNNR data.
21 YHCG Y output high frequency component coring gain 1111
22 HSSL Hsync slice level 12 *
23 VSSL Vsync slice level 8 *
24 ADCL ADC clock delay 3 *
NRMD=0 NRMD=1 NRMD=2 NRMD=3
25 D2GA Moving detection gain 4444
26 KILR Killer detection reference 3*
3D-COMB uPD64082
Reg.No & Name FUNCTION
27 OP Option: Selection of comb filter&recursive n.reduction types. 1*
UHF/VHF CVideo1 SVideo1 CVideo2 SVideo2 CVideo3 SVideo3 CVideo4
28 NR1 Noise reduction on/off 00101010
29 NR2 SNNR control on/off 0*
30 WSL Noise level detection level data 0-255 Read Data
31 HPLL H-PLL filter 1 *
32 BPLL Burst PLL filter 1 *
33 FSCF Burst extraction gain 0*
34 PLLF PLL loop gain 1 *
UHF/VHF Video1-4 Video5&6
35 CC3N Selection if a line-comb filter C separation filter characteristic 000
36 HDP Fine adjustment of the system H-phase 5*
37 BGPS Internal 4*
38 BGPW 10 *
39 TEST Test bit (0:Normal mode 1:Test mode) * forbidden setting 0*
40 WSC Amount of noise detection coring 1*
UHF/VHF & Video1-4 Video5&6
41 LIND DRC-M line-doubling setting for non-standard signals UHF/VHF&Video1-4 02
42 PFGO (YPFG offset at GR on) * Not used 3*
SNNR=0 SNNR=1 SNNR=2 SNNR=3
#16 VAPG 0000
