– 98 –
KP-HR432K90/HR532K90/HR532N90/HW572K90
RM-Y909KRM-Y908RM-Y909K RM-Y909K
1 2
2.2Vp-p (H)
1.9Vp-p (H)
• U(2/3) BOARD WAVEFORMS
• CG BOARD WAVEFORMS
1
129.5Vp-p (H)
• CR BOARD WAVEFORM
1
141.5Vp-p (H)
• CB BOARD WAVEFORM
97.5Vp-p (H)
1
3.5Vp-p (20Mhz)
6
• B(4/4) BOARD WAVEFORMS
5
1.8Vp-p (74.175824MHz)
• B(3/4) BOARD WAVEFORMS
1 2 3 4
4.5Vp-p (H)
4.5Vp-p (H)
4.2Vp-p (H) 3.1Vp-p (H)
• B(1/4) BOARD WAVEFORMS
1 2 3 4
0.9Vp-p (V)
1.9Vp-p (V)
0.4Vp-p (V) 1.5Vp-p (V)
• AD(2/2) BOARD WAVEFORMS
5 6
0.6Vp-p (V) 1.6Vp-p (V)
9
5Vp-p (V)
8
2.9Vp-p (V)
12MHz
7
5.2Vp-p (H)
• AD(1/2) BOARD WAVEFORMS
• D(1/3) BOARD WAVEFORMS
1
62.6Vp-p (V)
2 3
114Vp-p (H)
1.05kVp-p (H)
• D(3/3) BOARD WAVEFORMS
To Next Page
