— 16 —
KV-27FV310/29FV310/32FV310/36FV310
HV PROTECTOR CHECK-HIGH LIGHT
CONDITION
1. Short across C8002, C8021, C8301, C8012 and C8015.
2. Open pin 10 (ABL) of IC301 (YCJ).
3. Set video to white eld. Set HV current load to iabl = 2.74 ± 0.05mA
for 27/29” and iabl = 3.04 ± 0.05mA for 32/36” by adjusting picture
and brightness to maximum condition.
4. Adjust VR jig to obtain 33.10 ± 0.2kV for 27/29” and 34.25 ± 0.2kV
for 32/36”.
5. Remove short from C8002 and conrm that hold down activates.
6 Short C8002 again and conrm that HV recovers.
7 Then readjust precision VR jig to obtain 31.0 ± 0.2kV for 27/29” and
32.0 ± 0.2kV for 32/36”.
8. Remove shorts from C8002, C8021 and C8301.
9. Conrm that hold down does not activate.
10.Remove shorts from C8012, C8015.
SECTION 3: SAFETY RELATED ADJUSTMENTS
3-1. X RV8002 CONFIRMATION METHOD
(HV HOLD-DOWN CONFIRMATION) AND
READJUSTMENTS
Always perform the following adjustments when replacing the following
components marked with a
Y
mark on the schematic diagram:
D BOARD: HV HOLD DOWN
D8022, IC8001, IC8004, IC8005, RV8002
IC8104, R8014, R8015, R8016,
R8017, R8019, R8021, R8046,
R8052, R8072, R8078, R8079,
R8082, R8091, R8095
GK BOARD:
IC601
Part Replaced ( ) Adjustment ( )
PREPARATION BEFORE CONFIRMATION
Equipment: HV meter, DVM, Analog Current meter.
Condition: AC input voltage: 130 (+ 2) VAC.
Set condition: Reset condition.
Signal Input: All black video signal for Cut off, All white signal for High
light.
HV PROTECTOR CHECK-CUT OFF
CONDITION
1. Remove D board and carefully lift as necessary to gain access to the
bottom of the board. Open ABL pin 1 on RHT (T8001) and connect
analog current meter.
2. Make Cut Off condition. Input all black video signal and set picture
and brightness to min., ABL current should be approximately 0.15 ±
0.05mA for 27/29” and 0.16 ± 0.05mA for 32/36”.
3. Short across C8002, C8021 and C8301.
4. Turn off the set and install precision VR jig (initially set to 100K) to IC
8005 pin 1 and GND (C8076 -). Restore power and adjust to obtain
34.6 ± 0.2kV for 27/29” and 36.0 ± 0.2kV for 32/36”.
5. Remove short from C8002 and conrm that hold down activates.
6. Short C8002 again and conrm that HV recovers.
7. Then readjust precision VR jig to obtain 31.5 ± 0.2kV for 27/29” and
32.5 ± 0.2kV for 32/36”.
8. Remove short from C8002, C8021 and C8301.
9. Conrm that hold down does not activate
.
Y
X
