— 63 —
KV-27FV310/29FV310/32FV310/36FV310
*
Items marked with an asterisk are not stocked since they
are seldom required for routine service. Expect some delay
when ordering these components.
RESISTORS
• All resistors are in ohms
• F : nonfl ammable
• All variable and adjustable resistors
have characteristic curve B, unless
otherwise noted.
REF. NO. PART NO. DESCRIPTION VALUES
The components in this manual identifi ed by the following
symbol: indicate parts that have been carefully factory-
selected to satisfy regulations regarding X-ray radiation for
each set.
Should replacement be required for one of these
components, replace only with the value originally used.
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et
une marque
!
sont critiques pour la securite.
Ne les remplacer que par une piece portant le
numero specifi e.
When ordering parts by reference
number, please include the board name.
A
REF. NO. PART NO. DESCRIPTION VALUES
A
* A-1302-089-A A BOARD, COMPLETE
(KV-27FV310/29FV310(N) ONLY)
* A-1302-106-A A BOARD, COMPLETE(KV-32FV310 ONLY)
* A-1302-129-A A BOARD, COMPLETE(KV-36FV310 ONLY)
* A-1302-166-A A BOARD, COMPLETE(KV-29FV310(S) ONLY)
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C001 1-164-315-11 CERAMIC CHIP 470pF 5% 50V
C002 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C003 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C004 1-126-947-11 ELECT 47µF 20% 35V
C005 1-164-739-11 CERAMIC CHIP 560pF 5% 50V
C006 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C007 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C008 1-126-960-11 ELECT 1µF 20% 50V
C009 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C014 1-162-975-11 CERAMIC CHIP 24pF 5% 50V
C015 1-162-975-11 CERAMIC CHIP 24pF 5% 50V
C016 1-126-935-11 ELECT 470µF 20% 16V
C017 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C018 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C020 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C026 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C027 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C028 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C029 1-126-960-11 ELECT 1µF 20% 50V
C030 1-165-176-11 CERAMIC CHIP 0.047µF 10% 16V
C031 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C032 1-126-964-11 ELECT 10µF 20% 50V
C033 1-125-837-91 CERAMIC CHIP 1µF 10% 6.3V
C034 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C035 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C036 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C037 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C038 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C039 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C041 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C043 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C044 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C045 1-126-964-11 ELECT 10µF 20% 50V
C046 1-126-964-11 ELECT 10µF 20% 50V
C047 1-126-941-11 ELECT 470µF 20% 25V
C048 1-115-416-11 CERAMIC CHIP 0.001µF 5% 25V
C049 1-126-964-11 ELECT 10µF 20% 50V
C050 1-126-941-11 ELECT 470µF 20% 25V
C051 1-126-947-11 ELECT 47µF 20% 35V
C052 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V
C053 1-135-834-91 CERAMIC CHIP 2.2µF 6.3V
C054 1-126-963-11 ELECT 4.7µF 20% 50V
C055 1-126-933-11 ELECT 100µF 20% 16V
C056 1-135-834-91 CERAMIC CHIP 2.2µF 6.3V
C057 1-135-834-91 CERAMIC CHIP 2.2µF 6.3V
C060 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C062 1-125-837-91 CERAMIC CHIP 1µF 10% 6.3V
C065 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C101 1-115-416-11 CERAMIC CHIP 0.001µF 5% 25V
C102 1-115-416-11 CERAMIC CHIP 0.001µF 5% 25V
C111 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C120 1-162-915-11 CERAMIC CHIP 10pF 0.50pF 50V
C121 1-162-915-11 CERAMIC CHIP 10pF 0.50pF 50V
C122 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C133 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C200 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C201 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C202 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C203 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C206 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
SECTION 7: ELECTRICAL PARTS LIST
